Keeping a firm grip on the air conditioner carefully place the unit into the window open-
ing so the bottom of the air conditioner frame is against the window sill. Carefully close
the window behind the top rail of the unit.
Extend the side panels out against the window frame.
Front
Side
Horizontal or inclined about 3°
Upper guide rail
Lower guide rail
Window frame
6
Use 5 Type A screws to secure the frame of the flexible screen to the window frame
and sash.
Window frame
windowsill
