Sharp AF-S80CX User Manual

35
AF-S80CX
REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CABINET AND UNIT PARTS
1- 1 CMOTLB003JBEZ Fan motor 1 BM
1- 2 DCHS-A364JBTA Base pan ass’y 1 BC
1- 3 PFPFPB137JBE0 Base pan insulator 1 AF
1- 4 PFPFPB138JBE0 Base pan insulator 1 AF
1- 5 CCAB-A318JBKZ Cabinet ass’y 1 BB
1- 6 CWAK-C205JBKZ Top duct ass’y 1 AS
1- 7 HPNLCA805JBFA Control panel 1 AE
1- 8 HPNLCA814JBEA Control panel 1 AS
1- 9 PSEL-B825JBE0 Insulator 1 AE
1-10 LBND-A042JBE0 Wire fixing band 3 AC
1-11 LHLDW0364JBE0 Wire holder 1 AA
1-12 PSHE-A172JBE0 Protect sheet 1 AC
1-13 NFANPA078JBF0 Propeller fan 1 AU
1-14 NFANSA027JBF0 Centrifugal fan 1 AU
1-15 PFILMA164JBEA Air filter 1 AK
1-16 PKESPA034JBF0 Condenser shroud 1 AV
1-17 PKESSA057JBF0 Orifice 1 AK
1-18 PSEL-A827JBE0 Evaporator insulator 1 AB
1-19 PSEL-A994JBE0 Orifice insulator 1 AB
1-20 PSEL-A828JBE0 Motor insulator 1 AB
1-21 TLABMA326JBRZ Feature card 1 AE
1-22 PSEL-C085JBEZ Tube insulator 1 AC
1-23 PSKR-A104JBF0 Bulkhead 1 AS
1-24 PSRA-A078JBF0 Drain tray 1 AD
1-25 MJNTPA090JBFA Louver link 1 AC
1-26 MLOV-A333JBFA Horizontal louver 4 AC
1-27 MJNTPA089JBFA Louver joint 1 AC
1-28 MLOV-A321JBFA Vertical louver A 1 AC
1-29 MLOV-A322JBFA Vertical louver B 3 AC
1-30 MSPR-A148JBEZ Louver spring 2 AF
1-31 LANG-A213JBTA Top inst.angle 1 AF
1-32 LPLTMA087JBP0 Condenser cover 1 AB
1-33 GWAKPA151JBFA Front panel 1 AV
1-34 PSEL-B845JBE0 Insulator 1 AB
1-35 TLABBA110JBRA Sharp badge 1 AB
1-36 TLABKA564JBE0 Number card 1 AC
1-37 TLAB-C216JBEZ Energy card 1 AC
1-38 TSPC-E076JBRZ Name badge 1 AC
1-39 LHLD-A315JBF0 Thermistor holder 1 AE
1-40 PFPFPB745JBE0 Comp-cushion 1 AE
1-41 DSKR-A124JBKZ Bulkhead ass’y 1 AY
1-42 TLAB-B482JBR0 Energy start label 1 AA
CONTROL BOX PARTS
2- 1 DPLT-A056JBWZ Cont. box angle ass’y 1 AK
2- 2 LBNDKA058JBWZ Capacitor clamp 1 AD
2- 3 DPLT-A038JBW0 Cont. box cover ass’y 1 AK
2- 4 DPWBFA279JBKZ Control board unit 1 BL
2- 5 PSPA-A084JBE0 Spacer 2AC
2- 6 PSPA-A085JBE0 Spacer 1AC
2- 7 QACC-A260JBZZ Power supply cord 1 AS
2- 8 QFS-AA048JBE0 Fuse 1AB
2- 9 TLABCB604JBRZ Wiring diagram 1 AA
2-10 QW-VZC561JBE0 Lead wire 1 AD
2-11 QW-VZD376JBE0 Compressor cord 1 AR
2-12 RC-HZA256JBE0 Fan motor capacitor 1 AM
2-13 RC-HZA136JBE0 Running capacitor 1 AU
2-14 RH-HXA006JBZZ Thermistor 1 AK
2-15 LBND-A042JBE0 Wire fixing band 3 AC
2-16 QW-VZC366JBE0 Lead wire 1 AD
2-17 PPLT-A300JBEZ Insulating sheet 1 AF
2-18 PPLT-A305JBEZ Insulating sheet 1 AA
CYCLE PARTS
3- 1 PCMPRA368JBEZ Compressor 1 CB
3- 2 PCON-A483JBEZ Condenser 1 BP
3- 3 PEVA-A465JBEZ Evaporator 1 BN
3- 4 DCPY-A277JBKZ Capillary tube ass’y 1 AX
3- 5 RHOG-A130JBE0 Overload relay 1 AW
