Sharp AN-3DG20-EL

EN-5
Using the 3D Glasses
Switching to 3D and 2D Mode
When viewing 3D images, you can slide the switch
between 2D and 3D modes. This is useful when several
people are viewing 3D images on the same TV with
some people wanting to watch in 3D and some people
wanting to watch in 2D.
■ Viewing 2D images
When you slide the switch to 2D while viewing 3D
images, the 3D images switch to 2D images.
■ Viewing 3D images
When you slide the switch to 3D while viewing 2D
images, the 2D images switch to 3D images.
Usage Range of the 3D Glasses
The 3D Glasses can be used by receiving an infrared
signal sent from the TV.
The 3D Glasses turn off automatically after 10 minutes if
no signal is received from the TV.
■ Operating range
From directly in front of the 3D infrared emitter on
the TV: approx.17 ft (5 m)
(within approx. 30° horizontally and 20° vertically)
Recharging the 3D glasses
When the battery power is low, the LED light blinks one
time per second. If the 3D glasses battery is low, you can
recharge the 3D glasses by connecting the supplied USB
cable to the TV and the USB terminal on the 3D glasses.
1 Turn off the TV, and then slide the switch on the
3D glasses to OFF.
2 Connect the cable shown at step 3 of this
procedure and then turn on the TV. Make sure the
cable is connected before turning on the TV.
• The LED light blinks approximately every two
seconds, and then starts recharging.
• When the LED light goes off, the recharge is
complete. It takes approximately 90 minutes to
complete the recharge.
• Insert the USB cable again if the LED light blinks
on and off once every 0.5 seconds. If it still
doesn’t respond, inquire with a retail dealer or
ELITE TV customer service.
3 After the recharge has completed, turn off the
TV, and then remove the USB cable from the 3D
glasses.
1 USB cable (supplied accessory)
2 USB terminal
CAUTION
• Do not recharge while wearing the 3D glasses.
NOTE
• Be sure to turn on the TV when you recharge the 3D
glasses. If the TV is turned off, the 3D glasses may
not recharge.
• When you recharge the 3D glasses, only connect the
supplied USB cable to a USB terminal on the TV.
• The battery will not recharge during usage with the
USB cable connected. The 3D Glasses battery will
not be recharged if the switch is set to 2D or 3D. To
recharge the battery, set the switch to OFF.
• Recharge the battery within the operating temperature
(10°C–40°C/50°F–104°F). The battery may not be able
to recharge outside of the operating temperature.
Using the 3D glasses with power
supply
If you slide the switch to 3D or 2D after taking steps
1 and 2 in Recharging the 3D glasses, you will be
able to supply power to the 3D glasses while using the
glasses (battery will not be recharged).
NOTE
• Do not move around while wearing the 3D glasses.
Doing so may result in getting your feet caught in the
USB cable, the TV falling or other accidents that may
cause injury.
• When you supply power to the 3D glasses, only
connect a USB cable (commercially available) to a USB
terminal on the TV.
• When you use the USB cable connecting the 3D
glasses, be careful not to get your feet caught in the
USB cable. It may result in falling or other accidents
that may cause injury.
