13
AH-X08BE/10BE/13BE
AY-X08BE/10BE/13BE
AY-X08BE-C/10BE-C
AU-X08BE/10BE/13BE
AE-X08BE/10BE/13BE
AE-X08BE-C/10BE-C
For Model AH-X08BE/X10BE/X13BE, AY-X08BE/X08BE-C/X10BE/X10BE-C/X13BE
DESCRIPTION MODEL REMARKS SITE
Indoor fan motor ML-A901 220 - 240V, 50Hz AH, AY
Indoor fan motor capacitor – 430V, 2µF AH, AY
Transformer – Primary; AC 220 - 240V, 50Hz AH, AY
Secondary; AC19V, 50Hz
WPE1 – QFS-GA027JBE0 (250V, 3A) AH, AY
or QFS-GA040JBZZ (250V, 3A)
For Model AE-X10BE/X10BE-C
Compressor HV237A1-S15DK 3-PHASE Induction motor AE-X10BE
Compressor HV187X1-S12F3 3-PHASE Induction motor AE-X10BE-C
Outdoor fan motor ML-A902 220 - 240V, 50Hz 220V, 60Hz –
Outdoor fan motor capacitor – 430V, 1.5µF –
WPE1 – QFS-GA033JBZZ(250V, 15A) –
WPE2 – QFS-GA015JBE0(250V, 10A) –
WPE3 – QFS-GA027JBE0 (250V, 3A) –
or QFS-GA040JBZZ (250V, 3A)
For Model AE-X08BE/X08BE-C
Compressor HV166A1-S10DK 3-PHASE Induction motor AE-X08BE
Compressor 44A07QV2JD 3-PHASE Induction motor AE-X08BE-C
Outdoor fan motor ML-A902 220 - 240V, 50Hz 220V, 60Hz –
Outdoor fan motor capacitor – 430V, 1.5µF –
WPE1 – QFS-GA033JBZZ(250V, 15A) –
WPE2 – QFS-GA015JBE0(250V, 10A) –
WPE3 – QFS-GA027JBE0 (250V, 3A) –
or QFS-GA040JBZZ (250V, 3A)
For Model AU-X08BE/X10BE
Compressor 2RV110N5EA04 3-PHASE Induction motor –
Outdoor fan motor ML-A902 220 - 240V, 50Hz 220V, 60Hz –
Outdoor fan motor capacitor – 430V, 1.5µF –
WPE1 – QFS-GA033JBZZ(250V, 15A) –
WPE2 – QFS-GA015JBE0(250V, 10A) –
WPE3 – QFS-GA027JBE0 (250V, 3A) –
or QFS-GA040JBZZ (250V, 3A)
For Model AU-X13BE/AE-X13BE
Compressor HV237A1-S15DK 3-PHASE Induction motor AU, AE
Outdoor fan motor ML-A903 220 - 240V, 50Hz 220V, 60Hz AU, AE
Outdoor fan motor capacitor – 430V, 2.0µF AU, AE
WPE1 – QFS-GA014JBE0(250V, 20A) AU, AE
WPE2 – QFS-GA019JBE0(250V, 20A) AU, AE
WPE3 – QFS-GA027JBE0 (250V, 3A) AU, AE
or QFS-GA040JBZZ (250V, 3A) AU
ELECTRICAL PARTS
