Sharp AY-X08BE Service Manual

4
AH-X08BE/10BE/13BE
AY-X08BE/10BE/13BE
AY-X08BE-C/10BE-C
AU-X08BE/10BE/13BE
AE-X08BE/10BE/13BE
AE-X08BE-C/10BE-C
MODEL
I NDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT
ITEMS AY-X10BE AE-X10BE AY-X10BE-C AE-X10BE-C AY-X13BE AE-X13BE
Cooling capacity (Min. ~ Max.) kW 2.8(0.7
_
3.3) 2.8(0.9
_
3.3) 3.6(0.9
_
4.2)
Heating capacity (Min. ~ Max.) kW 3.7(0.7
_
5.0) 3.7(0.9
_
5.0) 4.8(1.0
_
6.2)
Moisture removal(at cooling) Liters/h 0.8 0.8 1.3
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage range V 198 to 264
Rated voltage V 220 - 240
Cool A 4.3
_
4.0 4.3
_
4.0 5.5
_
5.1
Rated current Heat A 4.8
_
4.4 4.8
_
4.4 6.8
_
6.2
Cool W 930 930 1200
Rated input Heat W 1050 1050 1480
Cool % 98
_
97 98
_
97 99
_
98
Power factor Heat % 99
_
99 99
_
99 99
_
99
Type Hermetically sealed rotary type
Compressor Model HV237A1-S15DK HV187X1-S12F3 HV237A1-S15DK
Oil charge 455cc (SUNISO 4GSD) 370cc (SUNISO 4GSD) 455cc (SUNISO 4GSD)
Evaporator Louver Fin and Grooved tube type
Refrigerant system Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant volume 850g 850g 880g
De-lce system Micro computer controled reversed systems
Noise level
High dB(A) 36 43 36 43 38 48
(at cooling)
Med. dB(A) 32 – 32 – 33 -
Low dB(A) 27 – 27 – 29 -
Fan system
Drive Direct drive
Air flow quantity High m
3
/min. 9.8 27.7 9.8 27.7 9.3 30
(at cooling) Med. m
3
/min. 8.2 – 8.2 – 8.1 –
Low m
3
/min. 6.1 – 6.1 – 6.6 –
Fan Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"
Drain piping mm O.D ø 18
Others
Compressor: Thermal protector
Safety device Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Width mm 815 780 815 780 815 780
Net dimensions Height mm 278 540 278 540 278 540
Depth mm 198 269 198 269 198 269
Net weight kg 10 35 10 36 10 39
Note: The condition of star " " marked item are ‘ISO5151’ : 1994(E), condition T1.
