Sharp AY-X08BE Service Manual

48
AH-X08BE/10BE/13BE
AY-X08BE/10BE/13BE
AY-X08BE-C/10BE-C
AU-X08BE/10BE/13BE
AE-X08BE/10BE/13BE
AE-X08BE-C/10BE-C
REF. NO. PART NO. DESCRIPTION Q'TY CODE
HOW TO ORDER REPLACEMENT PARTS
To have your order filled prompty and correctly, please furnish the following information.
1. MODEL NUMBER 2. REF. NO. 3. PART NO. 4. DESCRIPTION
2-16 VHPGL6ZS27+-6 LED (LED102) 1 AG
2-17 VHPSL326422-6 LED (LED121) 1 AP
2-18 PCOV-A611JBWZ Control box cover 1 AF
2-19 PCOV-A610JBWZ Terminal cover 1 AE
2-20 RRMCUA001JBZZ Photo detector unit (IC201) 1 AK
2-21 QFS-GA040JBZZ Fuse 3A 250V (WPE1) 1 AE
2-22 VHIKID65783-1 IC (IC6) 1 AK
2-23 RIC--A022BDE0 IC (IC3) 1 AE
2-24 VHIBR24C01A-6 IC (IC8) 1 AF
2-25 RH-TZA098JBE0 Transistor (Q1, Q2) 2 AB
2-26 RH-VZA020JBE0 Varistor (CNR1) 1 AE
2-27 RH-VXA002JBZZ Varistor (NR1) 1 AF
2-28 RH-IZA149JBE0 IC (IC2) 1 AE
2-29 VHPGL6ZE27+-6 LED (LED103 - 111) 9 AG
2-30 RRLYDA010JBZZ Relay (RY1) 1 AN
2-31 RTRN-A287JBZZ Transformer (TRANS 1) 1 AT
2-32 VHPGL6ZR27+-6 LED (LED101) 1 AF
2-33 VHRPC817X7/1B Photo coupler (PC1) 1 AD
2-34 VHRPC853H//-6 Photo coupler (PC2) 1 AG
2-35 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-36 VHD1SR139-6-1 Diode (D7-D9) 3 AB
2-37 VHD1SR35-4A-1 Diode (D1-D5) 5 AC
2-38 VHEHZ24-2//-1 Zenner diode (ZD1) 1 AB
CYCLE PARTS
3- 1 CPIPCA678JBKZ Tube assembly [AH-X08BE/10BE, AY-X08BE/X08BE-C] 1 BG
3- 1 CPIPCA679JBKZ Tube assembly [AH-X13BE, AY-X13BE] 1 BH
3- 1 CPIPCA690JBKZ Tube assembly [AY-X10BE/X10BE-C] 1 BH
3- 2 PSEN-A004JBK0 Flare nut assembly (1/4") 1 AE
3- 3 PSEN-A005JBK0 Flare nut assembly (3/8") 1 AG
3- 3 PSEN-A016JBK0 Flare nut assembly (1/2") 1 AR
3- 4 PVLV-0341JBE0 Flare union (1/4") 1 AG
3- 5 PVLV-0342JBE0 Flare union (3/8") 1 AH
3- 5 PVLV-0406JBE0 Flare union (1/2") 1 AK
3- 6 DEVA-A128JBKZ Evaporator sub assembly [AY-X10BE/X10BE-C] 1 BT
3- 6 DEVA-A123JBKZ Evaporator sub assembly [AH-X08BE] 1 BR
3- 6 DEVA-A122JBKZ Evaporator sub assembly [AH-X13BE/AY-X13BE] 1 BT
3- 6 DEVA-A121JBKZ Evaporator sub assembly [AH-X10BE/AY-X08BE/X08BE-C] 1 BS
ACCESSORY PARTS
4- 1 CRMC-A529JBEZ Remote control [AH-X08BE/X10BE/X13BE] 1 BD
4- 1 CRMC-A528JBEZ Remote control [AY-X08BE/X08BE-C/X10BE/X10BE-C/X13BE] 1 BB
4- 2 UBATUA027JBE0 Battery pack 1 AE
4- 3 LHLD-A477JBFA
Cord holder(for covering the terminal board of indoor unit) 1AE
4- 4 XTTSD40P16000 Tapping screw (for fixing the cord holder) 1 AA
4- 5 LX-NZA207JBEZ Special nut (for fixing long screw steadily) 9 AE
4- 6 LPFT-A029JBF0 Drain joint [AY-X08BE/X08BE-C/X10BE/X10BE-C/X13BE] 1 AD
4- 7 PPLTNA058JBWZ Mounting angle 1 AS
4- 8 XTTSD45P30000 Long screw 8 AA
4- 9 TINSEA262JBRZ Operation manual 1 AM
4-10 TINS-A664JBRZ Installation manual 1 AE
4-11 TINS-A665JBRZ Installation manual 1 AE
4-12 LX-BZA106JBE0 Special screw (for hanging remote controller) 1 AE
SCREWS
5- 1 LX-BZA075JBE0 Special screw (for earth) 1 AA
PACKING PARTS
6- 1 CPADBA038JBKZ Packing pad assembly 2 AK
6- 2 SPAKCA745JBEZ Packing case [AH-X08BE] 1 AR
6- 2 SPAKCA743JBEZ Packing case [AH-X10BE] 1 AR
6- 2 SPAKCA744JBEZ Packing case [AH-X13BE] 1 AR
6- 2 SPAKCA742JBEZ Packing case [AY-X08BE] 1 AR
6- 2 SPAKCA972JBEZ Packing case [AY-X08BE-C] 1 AQ
6- 2 SPAKCA740JBEZ Packing case [AY-X10BE] 1 AR
6- 2 SPAKCA971JBEZ Packing case [AY-X10BE-C] 1 AR
6- 2 SPAKCA741JBEZ Packing case [AY-X13BE] 1 AR
