AH-X075E/X095E
AU-X075E/X095E
AY-X075E/X095E
AE-X075E/X09SE
2-3 Overcurrent protection
(1) Compressor lock detection
if
the
set
value
(3.0
A)
of
AC
current
is
exceeded
at
19
to
23
Hz
when
operation
begins,
operation
is
stopped.
In
this
case,
the
compressor
outdoor
fan
does
not
stop,
and
170
seconds
after
operation
is
stopped,
another
try
will
be
made.
Three
retries
are
allowed.
On
the
fourth
retry,
a
complete
stop
request
signal
is
sent
to
the
indoor
unit,
and
the
outdoor
unit
will
remain
stopped
until
reset
is
performed.
At
this
time,
the
3-minute
delay
for
control
of
the
outdoor
unit
will
not
function;
therefore,
do
not
cancel
by
removing
the
plug
and
cutting
the
power.
DC
overcurrent
detection,
AC
overcurrent
detection
To
protect
against
overcurrent
due
to
sudden
changes
in
load,
the
compressor
is
stopped
if
the
set
value
30
A
DC
is
exceeded
in
the
DC
section,
or
the
set
value
8.5
A
AC
is
exceeded
in
the
AC
section.
in
this
case,
the
outdoor
fan
does
not
stop,
and
170
seconds
after
operation
is
stopped,
another
try
will
be
made.
Three
retries
are
allowed.
On
the
fourth
retry,
a
complete
stop
request
signal
is
sent
to
the
indoor
unit,
and
the
outdoor
unit
will
remain
stopped
until
reset
is
performed.
At
this
time,
the
3-minute
delay
for
control
of
the
outdoor
unit
will
not
function;
therefore,
do
not
cancel
by
removing
the
plug
and
cutting
the
power.
(2
——
2-4 Compressor protector control
If
the
temperature
of
the
compressor
chamber
exceeds
114°C,
the
compressor
is
stopped.
In
this
case,
the
outdoor
fan
does
not
stop,
and
when
the
compressor
chamber
temperature
decreases
to
100°C
three
minutes
after
operation
is
stopped,
another
try
will
be
made.
Three
retries
are
allowed.
On
the
fourth
retry,
a
complete
stop
request
signal
is
sent
to
the
indoor
unit,
and
the
outdoor
unit
will
remain
stopped
until
reset
is
performed.
At
this
time,
the
3-minute
delay
for
contro!
of
the
outdoor
unit
will
not
function;
therefore,
do
not
cancel
by
removing
the
plug
and
cutting
the
power.
2-5
Power
transistor
module
protector
If
the
temperature
of
the
chips
in
the
power
transistor
module
exceeds
105
°C,
the
compressor
is
stopped.
In
this
case,
the
outdoor
fan
does
not
stop,
and
when
the
temperature
of
the
chips
in
the
power
transistor
module
decreases
to
105
°C
170
seconds
seconds
after
operation
is
stopped,
another
try
will
be
made.
Three
retries
are
allowed.
On
the
fourth
retry,
a
complete
stop
request
signal
is
sent
to
the
indoor
unit,
and
the
outdoor
unit
will
remain
stopped
until
reset
is
performed.
At
this
time,
the
3-minute
delay
for
control
of
the
outdoor
unit
will
not
function;
therefore,
do
not
cancel
by
removing
the
plug
and
cutting
the
power.
2-6 Power factor module
If
a
voltage
error
(over
400
V),
current
error
(over
17
A),
or
temperature
error
(over
90°C)
is
detected
in
the
power
factor
module,
170
seconds
the
compressor
is
stopped.
In
this
case,
the
outdoor
fan
does
not
stop,
and
170
seconds
after
operation
is
stopped,
another
try
will
be
made.
Three
retries
are
allowed.
On
the
fourth
retry,
a
complete
stop
request
signal
is
sent
to
the
indoor
unit,
and
the
outdoor
unit
will
remain
stopped
until
reset
is
performed.
At
this
time,
the
3-
minute
delay
for
control
of
the
outdoor
unit
will
not
function;
therefore,
do
not
cancel
by
removing
the
plug
and
cutting
the power.
2-7 Serial signals
(1)
Serial
signals
consist
of
all
96-bit
signals.
(2)
If
the
outdoor
unit
does
not
receive
a
serial
signal,
it
will
stop
approximately
30
seconds
later.
Note
that
this
is
true
only
of
normal
operation;
in
test
mode,
it
does
not
stop
and
operation
takes
place
based
on
the
test
mode
commands.
2-8 Four-way rotary valve
The
four-way
rotary
valve
will
not
switch
when
there
is
a
large
difference
in
refrigerant
pressure.
To
make
the
four-way
rotary
valve
switch
normally,
switching
is
delayed
by
approximately
3
minutes
and
the
refrigerant
pressure
difference
is
decreased
first.
Also,
the
temperature
of
the
indoor
heat
exchanger
at
the
time
of
compressor
activation
and
the
temperature
150
minutes
after
activation
are
compared,
and
it
is
determined
whether
or
not
they
are
suitable
for
the
opera
mode
at
that
time.
If
they
are
not
suitable,
a
four-way
rotary
valve
error
results
and
the
compressor
is
stopped.
27
