Specifications
Model
AC28RNSYS
Function COOLING HEATING
Rated Voltage 200-240V
Frequency (Hz) (H/S) 50Hz
Total Capacity (W) (H/S/L):
Total Capacity (Btu/h) (H/S/L):
9000/8000/1000 (W)
30708/27296/3412 (Btu/h)
11000/8400/1300 (W)
37532/28661/4436 (Btu/h)
Power Input (W) (H/S/L) 2900/2390/300 (W) 4000/2510/350 (W)
Rated Input (W) 4200
Rated Current (A) 10.60 11.14
Air Flow Volume (m³/h) (SS/H/MH/M/ML/L/SL) 1200/1130/1060/990/920/850/780
Dehumidifying Volume (l/h) 2.70
EER / C.O.P. (W/W) 3.35/3.35
Model of Indoor Unit
AYX28NCJ
Fan Motor Speed (r/min) 1400/1300/1200/1100/
1000/850/750
1350/1300/1200/1100/
1000/850/750
Output of Fan Motor (w) 70
Fan Type-Piece Cross Flow
Diameter-Length (mm) 106x890
Evaporator Form Aluminium Fin-copper Tube
Row-Fin Gap (mm) 2-1.5
Coil length (l) x height (H) x coil width (L) 903x25.4x381
Swing Motor Model MP35CJ/MP24HB/MP24HC
Fuse (A) 3.15
Sound Pressure Level db (A) (SS/H/MH/M/ML/L/SL) 51/49/45/43/41/39/36
Sound Power Level dB (A) (SS/H/MH/M/ML/L/SL) 61/59/55/53/51/49/46
Dimension (WxDxH) (mm) 1178x264x326
Dimension of Package (LxWxH) (mm) 1256x414x364
Indoor Unit
Net Weight / Gross Weight (kg) 18/24
Model of Outdoor Unit
AEX28NCJ
Compressor Manufacturer/trademark MITSUBISHI
Compressor Type Rotary
L.R.A. (A) 40
Compressor RLA (A) 12
Compressor Power Input (W) 2450
Overload Protector 1NT11L-6233
Throttling Method Capillary
Working Temp Range (°C) -15°C~43°C
Condenser Aluminium Fin-copper Tube
Rows-Fin Gap (mm) 3-1.5
Coil length (I) x depth (D) x coil width (W) 960x57.15x748
Fan Motor Speed (rpm) 780
Output of Fan Motor (W) 90
Air Flow Volume of Outdoor Unit (m³/h) 4000
Fan Type-Piece Axial-flow
Fan Diameter (mm) 552
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IP24
Permissible Excessive Operating Pressure for the
Discharge Side (MPa)
4.3
Permissible Excessive Operating Pressure for the
Suction Side (MPa)
2.5
Sound Pressure Level dB (A) 58
Dimension (WxDxH) (mm) 980x427x790
Dimension of Package (LxWxH) (mm) 1083x488x855
Net Weight / Gross Weight (kg) 69/75
Outdoor
Unit
Refrigerant Charge (kg) 2.40
Liquid line diameter (mm) Ф6 Connection
Pipe
Gas line diameter (mm) Ф16
