SHARP(CHINA) INVESTMENT CO., LTD
7) Unfasten the front panel and pull forward it slightly. (4 circled spotsin
the picture are hooked.)
Open the horizontal louver.
Horizontal Louver
Pull the front panel toward in the direction shown the picture.
8) Remove the thermistor suppertor and the thermistor clip.Remove a
screw fixing the earth wire.
9) Remove the screw fixing on the control box cover from the control
box and pull it away.
10) Remove the 3 screw and the 5 connectors and remove the control
box.
Another one is iner
Back
5-2
