AY-XP08/10/13CE
AE-X08/10BE-C
AE-X13BE
REF. NO. PART NO. DESCRIPTION Q'TY CODE
2-16 VHPGL6ZS27+-6 LED (LED102) 1 AG
2-17 VHPSL326422-6 LED (LED121) 1 AP
2-18 PCOV-A611JBWZ Control box cover 1 AF
2-19 PCOV-A610JBWZ Terminal cover 1 AE
2-20 RRMCUA001JBZZ Photo detector unit (IC201) 1 AK
2-21 QFS-GA040JBZZ Fuse 3A 250V (WPE1) 1 AE
2-22 VHIKID65783-1 IC (IC6) 1 AK
2-23 RIC—-A022BDE0 IC (IC3) 1 AE
2-24 VHIBR24C01A-6 IC (IC8) 1 AF
2-25 RH-TZA098JBE0 Transistor (Q3 - Q7, Q9) 6 AB
2-26 RC-HZA329JBE0 Fan motor capacitor (C1) 1 AP
2-27 RH-VXA002JBZZ Varistor (NR1) 1 AF
2-28 RH-IZA149JBE0 IC (IC2) 1 AE
2-29 VHPGL6ZE27+-6 LED (LED103 - LED111) 9 AG
2-30 RTRN-A287JBZZ Transformer (TR1) 1 AT
2-31 VHPGL6ZR27+-6 LED (LED101) 1 AF
2-32 VHRPC817X7/1B Photo coupler (PC1) 1 AD
2-33 VHRPC853H//-6 Photo coupler (PC2) 1 AG
2-34 VHRS201D01/-6 Solid state relay (SSR1) 1 AK
2-35 VHD1SR139-6-1 Diode (D6, D8, D9) 3 AB
2-36 VHD1SR35-4A-1 Diode (D1- D5) 5 AC
2-37 VHEHZ24-2//-1 Zener diode (ZD1) 1 AB
2-38 RH-IZA140JBE0 IC (IC7) 1 AE
2-39 RDTC-A001KKE0 Gas sensor (GS1) 1 AW
2-40 VHRPR33MF11-6 Solid state relay (SSR2) 1 AX
2-41 VHPGL5BG502-1 LED (LED131) 1 AR
2-42 RSNSZA001JBZZ Dust sensor 1 BD
2-43 PFPFPB970JBEZ Sheet 1 AA
2-44 LHLD-A540JBFA Holder 1 AM
2-45 LHLD-A550JBRA Display cover 1 BE
2-46 LHLD-A560JBFA Sensor holder 1 AM
2-47 LHLD-A562JBFA Holder 1 AM
2-48 RH-IXA705JBZZ Micro computer (IC1) 1 AV
2-49 CKITTA002JBKZ Hi voltage unit ass'y 1 BA
CYCLE PARTS
3- 1 CPIPCA678JBKZ Tube ass’y (AY-XP08CE) 1 BG
3- 1 CPIPCA690JBKZ Tube ass’y (AY-XP10CE) 1 BH
3- 1 CPIPCA679JBKZ Tube ass’y (AY-XP13CE) 1 BH
3- 2 PSEN-A005JBKZ Flare nut ass’y (1/4") 1 AG
3- 3 PSEN-A004JBKZ Flare nut ass’y (3/8") (AY-XP08CE/XP10CE) 1 AE
3- 3 PSEN-A016JBKZ Flare nut ass’y (1/2") (AY-XP13CE) 1 AR
3- 4 PVLV-0341JBE0 Flare Union (1/4") 1 AG
3- 5 PVLV-0342JBE0 Flare Union (3/8") (AY-XP08CE/XP10CE) 1 AH
3- 5 PVLV-0406JBE0 Flare Union (1/2") (AY-XP13CE) 1 AK
3- 6 DEVA-A121JBKZ Evaporator sub ass’y (AY-XP08CE) 1 BS
3- 6 DEVA-A128JBKZ Evaporator sub ass’y (AY-XP10CE) 1 BT
3- 6 DEVA-A122JBKZ Evaporator sub ass’y (AY-XP13CE) 1 BT
ACCESSORY PARTS
4- 1 CRMC-A569JBEZ Remote control 1 BD
4- 2 UBATUA027JBE0 Battery pack 1 AE
4- 3 LHLD-A477JBFA Cord holder
(for covering the terminal board of indoor unit)
1AE
4- 4 XTTSD40P16000 Tapping Screw (for fixing the cord holder) 1 AA
4- 5 LX-NZA207JBEZ Special nut (for fixing long screw steadily) 9 AE
4- 6 PPLTNA058JBWZ Mounting angle 1 AS
4- 7 XTTSD45P30000 Long screw 8 AA
4- 8 LX-BZA106JBE0 Special screw (for hanging remote controller) 1 AE
4- 9 LPFT-A029JBF0 Drain joint 1 AD
4-10 GLEGGA008JBE0 Compressor cushion 4 AE
4-11 TINSEA298JBRZ Operation manual 1 AR
4-12 TINS-A710JBRZ Installation manual 1 AG
4-13 TINS-A711JBRZ Installation manual 1 AG
SCREW
5- 1 LX-BZA075JBE0 Special screw (for earth) 1 AA
PACKING PARTS
6- 1 CPADBA038JBKZ Packing Pad Ass’y 2 AK
6- 2 SPAKCA990JBEZ Packing case [AY-XP08CE] 1 AQ
6- 2 SPAKCA989JBEZ Packing case [AY-XP10CE] 1 AQ
6- 2 SPAKCA988JBEZ Packing case [AY-XP13CE] 1 AQ
To Next Page
