For Model AY-XP08CE/XP10CE/XP13CE

DESCRIPTION MODEL REMARKS SITE

Indoor fan motor ML-A915 220 - 240V, 50Hz AY

Indoor fan motor capacitor – 430V, 2µF AY

Transformer – Primary; AC 220 - 240V, 50Hz AY

Secondary; AC19V, 50Hz

WPE1 – QFS-GA040JBZZ (250V, 3A) AY

For Model AE-X08BE-C

Compressor 44A072QV2JD 3-PHASE Induction motor AE

Outdoor fan motor ML-A902 220 - 240V, 50Hz 220V, 60Hz AE

Outdoor fan motor capacitor – 430V, 1.5µF AE

WPE1 – QFS-GA033JBZZ(15A, 250V) AE

WPE2 – QFS-GA015JBE0(10A, 250V) AE

WPE3 – QFS-GA040JBZZ(3A, 250V) AE

For Model AE-X10BE-C

Compressor HV187X1-S12F3 3-PHASE Induction motor AE

Outdoor fan motor ML-A902 220 - 240V, 50Hz 220V, 60Hz AE

Outdoor fan motor capacitor – 430V, 1.5µF AE

WPE1 – QFS-GA033JBZZ(15A, 250V) AE

WPE2 – QFS-GA015JBE0(10A, 250V) AE

WPE3 – QFS-GA040JBZZ(3A, 250V) AE

For Model AE-X13BE

Compressor HV237A1-S15DK 3-PHASE Induction motor AE

Outdoor fan motor ML-A903 220 - 240V, 50Hz 220V, 60Hz AE

Outdoor fan motor capacitor – 430V, 2.0µF AE

WPE1 – QFS-GA014JBE0(20A, 250V) AE

WPE2 – QFS-GA019JBE0(20A, 250V) AE

WPE3 – QFS-GA040JBZZ(3A, 250V) AE
