Sharp AY-XP18GR - Part Names; Indoor Unit

ENGLISH
E-3
1 Air Purifying Filters
2 Inlet (Air)
3 Open Panel
4 AUX. Button
5 Air Filters
6 Receiver Window
7 Power Supply Cord
(AY-XP18GR only)
8 Indicator
9 Vertical Adjustment Louvres
0 Horizontal Adjustment
Louvres
q Outlet (Air)
w Remote Control
e FULL POWER Lamp
(green )
r SELF CLEAN Lamp
(green )
t PLASMACLUSTER Lamp
(blue)
y TIMER Lamp (orange )
u OPERATION Lamp (red )
NOTE: -Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
PART NAMES
