PART NAMES
1 Oven door with see-through window
Be careful with the edge of the oven door as it is glass
and could chip or break.
2 Door hinges
3 Waveguide cover:
DO NOT REMOVE.
4 Turntable motor shaft
5 Oven light
It will light when oven is operating or door is open.
6 Safety door latches
The oven will not operate unless the door is
securely closed.
7 Feature Guide Reference Panel
8 One touch DOOR OPEN button
Push to open door.
9 Nameplate
10 Removable turntable
The turntable will rotate clockwise or counter-
clockwise. Only remove for cleaning.
11 Removable turntable support
First, carefully place the turntable support in the
motor shaft in the center of the oven floor. Then,
place the turntable on the turntable support
securely.
12 Light cover
BOTTOM VIEW
(Front of Microwave)
(Rear of Microwave)
FRONT VIEW
12
16
2
34 5
10
11
6
8
9
7
