– 11 –
CD-C449W/K449W
CP-C449
1 Front Speaker 1. Net.......................... (A1) x1 11-2
2. Front Panel ............ (A2) x1
3. Screw ..................... (A3) x2
4. Screw ..................... (A4) x4
5. Screw ..................... (A5) x2
STEP REMOVAL
PROCEDURE
FIGURE
CP-C449
Figure 11-2
Be careful when installing the CD changer mechanism.
Install the CD changer mechanism on the CD player base after
the shift lever has been set in the highest position.
Figure 11-1
( U1 ) x4
ø3 x12mm
( V1 ) x1
ø2.6 x10mm
CD Changer
Mechanism
CD Mechanism
Shift Lever
CD Player Base
Screw driver
Woofer
Woofer
Net
(A1)x1
Baffle Board
(A2)x1
Tweeter
Tweeter
Super
Tweeter
(A5)x2
ø3x10mm
(A3)x2
ø3x10mm
(A4)x4
ø4x16mm
