CD-E700H
– 46 –
IC701 RH-iX0553AWZZ: System Microcomputer (IX0553AW) (2/2)
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Port Name Terminal NamePin No. Input/Output
Function
54 P120 O/C SW Input CD OPEN/CLOSE SW.
55 P117 MIC SW Input Mic switch input.
56* P116 KARA_LATCH Output Karaoke latch. (When not used. Connect to 0 V.)
57* P115 NO USE Output Open.
58* P114 NO USE Output Open.
59 P113 RDS RST Output RDS RAM reset.
60 P112 RDS RDDA Input RDS data input.
61 P111 RDS RDCL Output RDS clock.
62 P110 RDS READY Input RDS ready.
63 P107 ILU_LED1 Output Illumination LED1.
64* P106 ILU_LED2 Output Illumination LED2.
65* P105 ILU_LED3 Output Illumination LED3.
66* P104 FOR PLY_LED Output Forward play LED.
67* P103 REV PLY_LED Output Reverse play LED.
68* P102 STOP_LED Output Stop LED.
69 FIP30 DIST Input Distination input.
70 FIP29 S21 Output FL segment driver.
71-74 P97-P94 DIST 0-DIST 3 Output Distination output.
75-78 FIP24-FIP21 S16-S13 Output FL segment driver.
79 VLOAD VLOAD Input FL driver power supp. -30 V
80-91 FIP20-FIP9 S12-S1 Output FL segment driver.
92-100 FIP8-FIP0 G9-G1 Output FL grid driver.
