PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E700H
INTEGRATED CIRCUITS
IC1 VHILC78646E-1 J AY CD Servo,LC78646E
IC2 VHILA6574H+-1 J AN Focus/Tracking/Spin/Sled Driver,
LA6574H
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0553AWZZ J AX System Microcomputer,
IX0553AW
IC851 VHIKIA7812AP1 J AF Voltage Regulator,KIA7812AP
IC852 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810AP
IC853 VHIKIA7805AP1 J AF Voltage Regulator,KIA7805AP
IC854 VHIAN78L05/-1 J AE Voltage Regulator,AN78L05
IC855 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
IC901 VHISTK41242-1 J BB Power Amp.,STK41242
ICT21 VHILC72723/-1 J AR RDS Decorder,LC72723
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q4 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q101~104 VSKTC3200GR-1 J AC Silicon,NPN,KTC3200 GR
Q105~108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q111 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q112 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q113,114 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q301 VS2SC380-O/-1 J AC Silicon,NPN,2SC380 O
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q601~604 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q706~708 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q709,710 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q711 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
Q712 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q801 VSKTA1274Y/-1 J AE Silicon,PNP,KTA1274 Y
Q841 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q901~905 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q906 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
QT21 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
DIODES
D301,302 VHDDS1SS133-1 J AB Silicon,DS1SS133
D701 VHDDS1SS133-1 J AB Silicon,DS1SS133
D704 VHDDS1SS133-1 J AB Silicon,DS1SS133
D709~715 VHDDS1SS133-1 J AB Silicon,DS1SS133
D716 VHDDS1SS133-1 J AB Silicon,DS1SS133
D801,802 VHDD10XB60F-1 J AL Silicon,D10XB60F
D803~806 VHD1N4004S/-1 J AB Silicon,1N4004S
D842~845 VHD1N4004S/-1 J AB Silicon,1N4004S
1 D846 VHDDS1SS133-1 J AB Silicon,DS1SS133
D851,852 VHDDS1SS133-1 J AB Silicon,DS1SS133
D853 VHD1N4004S/-1 J AB Silicon,1N4004S
D855 VHDDS1SS133-1 J AB Silicon,DS1SS133
D856 VHDDS1SS133-1 J AB Silicon,DS1SS133
D857~859 VHDDS1SS133-1 J AB Silicon,DS1SS133
D905~907 VHDDS1SS133-1 J AB Silicon,DS1SS133
D909,910 VHD1N4004S/-1 J AB Silicon,1N4004S
D911,912 VHDDS1SS133-1 J AB Silicon,DS1SS133
LED701 VHP304VT2E1-1 J AC LED,Red,304VT2E1
LED703,704 VHPA503BC2E-1 J AN LED,White,A503BC2E
ZD1 VHEDZ3R3BSB-1 J AB Zener,3.3V,DZ3.3BSB
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
ZD801,802 VHEDZ6R2BSA-1 J AB Zener,6.2V,DZ6.2BSA
ZD803 VHEDZ300BSB-1 J AB Zener,30V,DZ30BSB
ZD852 VHEDZ8R2BSB-1 J AB Zener,8.2V,DZ8.2B
ZD902,903 VHEDZ120BSB-1 J AB Zener,12V,DZ12BSB
ZDT21 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
FILTERS
CF301,302 RFILF0072AFZZ J AG FM IF
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
1 PT801 RTRNP0468AWZZ J BE Power,Main
1 PT841 RTRNP0313AWZZ J AN Power,Sub
T303 RCILA0052AWZZ J AE AM Tracking
T306 RCILB0067AWZZ J AD OSC.,AM
T351 RCILI0019AWZZ J AD AM IF
COILS
L1 VP-XHR82K0000 J AC 0.82 µH,Choke
L103 VP-MK331K0000 J AB 330 µH,Choke
L341 RBLN-0002AWZZ J AE Balum
L342 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L354 RFILL0001AWZZ J AE Low Pass Filter
L701 VP-DH101K0000 J AB 100 µH,Choke
L702 VP-DH2R2K0000 J AB 2.2 µH,Peaking
1 L841 RCILZ0022AWZZ J AG Line Filter
L901,902 RCILZ0024AWZZ J AC 3 µH,Choke
L920,921 RCILZ0137AFZZ J AA 0.29 µH
LT21,22 VP-XH2R2K0000 J AB 2.2 µH,Choke
VARIABLE CAPACITOR
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0019AWZZ J AF Crystal,4.5 MHz
XL1 RCRM-0047AWZZ J AE Ceramic,16.9344 MHz
XL701 RCRSP0003AWZZ J AH Crystal,4.194304 MHz
XT21 RCRSP0018AWZZ J AG Crystal,4.332 MHz
CAPACITORS
C1 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C2 VCTYMN1CY103N J AA 0.01 µF,16V
C3 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C4 VCKYMN1HB102K J AA 0.001 µF,50V
C5 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C6 VCTYPA1CX104K J AB 0.1 µF,16V
C8 VCTYMN1CX272K J AA 0.0027 µF,16V
C9 RC-EZ0004AWZZ J AD 3.3 µF,16V,Electrolytic
C10 RC-EZY106AF1E J AB 10 µF,25V,Electrolytic
C11 RC-EZY224AF1H J AB 0.22 µF,50V,Electrolytic
C12 VCKYMN1HB101K J AA 100 pF,50V
C13 VCTYMN1EF223Z J AA 0.022 µF,25V
C14 RC-EZY107AF1A J AB 100 µF,10V,Electrolytic
C15 VCKYMN1HB102K J AA 0.001 µF,50V
C16 RC-EZY337AF0J J AA 330 µF,6.3V,Electrolytic
C17 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C19 VCTYMN1EF223Z J AA 0.022 µF,25V
C20,21 VCKYMN1HB102K J AA 0.001 µF,50V
C22 VCTYMN1CY103N J AA 0.01 µF,16V
C23,24 RC-EZY106AF1E J AB 10 µF,25V,Electrolytic
C25,26 VCQYKA1HM152K J AB 0.0015 µF,50V,Mylar
C27 VCTYMN1EF223Z J AA 0.022 µF,25V
C28~30 VCKYMN1HB101K J AA 100 pF,50V
C33 VCKYMN1HB101K J AA 100 pF,50V
C35 VCQYKA1HM473J J AB 0.047 µF,50V,Mylar
C36 VCEAZA1HW224M J AB 0.22 µF,50V,Electrolytic
C37 VCTYPA1CX104K J AB 0.1 µF,16V
C38 VCTYMN1CY103N J AA 0.01 µF,16V
C39~41 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C42 VCTYMN1CY103N J AA 0.01 µF,16V
C43 VCTYMN1EF223Z J AA 0.022 µF,25V
C44 VCKYMN1HB102K J AA 0.001 µF,50V
C45 VCCCMN1HH220J J AA 22 pF (CH),50V
C48 VCKYMN1HB102K J AA 0.001 µF,50V
C101,102 VCKYMN1HB561K J AA 560 pF,50V
C103 VCKYBT1HB181K J AA 180 pF,50V
C104 VCKYMN1HB181K J AA 180 pF,50V
C105,106 VCKYMN1HB561K J AA 560 pF,50V
C107~110 VCKYMN1HB331K J AA 330 pF,50V
– 1 –
CD-E700H
