PRICE
RANK
DESCRIPTIONNO. PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-E700H
CABINET PARTS
201 92LCAB4961AASY J Front Panel Ass’y
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 GCOVA1487AWSA J Cover,Cassette [Tape 1]
201- 3 GCOVA1488AWSA J AH Cover,Cassette [Tape 2]
201- 4 GDORF0118AWSA J AE Holder,Cassette [Tape 1]
201- 5 GDORF0119AWSA J AE Holder,Cassette [Tape 2]
201- 6 HDECQ0963AWSA J AG Panel,AMP.
201- 7 JKNBZ0921AWSA J AF Button,On/Stand-by/Tuning
201- 8 JKNBZ0922AWSA J AE Button,Open/Close
201- 9 JKNBZ0923AWSA J AG Button,Operation A
201-10 JKNBZ0924AWSA J AK Button,Operation B
201-11 JKNBZ0925AWSA J AL Button,Function
201-12 JKNBZ0926AWSA J AE Button,X-BASS/Equalizer
201-13 GCOVA1460AWSA J AC Cover,Sensor
201-14 GCOVA1351AWSA J AB Cover,Timer LED
201-15 MSPRD0151AWFJ J AB Cassette Spring,Tape 1
201-16 MSPRD0152AWFJ J AB Cassette Spring,Tape 2
201-17 MLIFP0008AWZZ J AD Damper
201-18 HBDGB1007AWSA J AD Badge,SHARP
201-19 JKNBZ0927AWSA J AF Button,RDS
202 92LCAB3838BASY J AN Side Panel Ass’y,Left
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3838CASY J AN Side Panel Ass’y,Right
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 GCAB-1197AWZZ J AM Loading Tray
205 GCAB-1215AWSA J AT Top Cabinet
206 GCOVA1486AWSA J AK Cover,CD Tray
207 GITAR1179AWSA J AM Rear Panel
208 KMECB0032AWZZ J BD Tape Mechanism Ass’y
208- 1 92LF513-894 J BE Head Plate Block [Tape 2]
208- 2 92LF525-357 J BD Motor with Pulley [Tape]
208- 3 92LF567-719 J –– Tape Mechanism PWB Ass’y
208- 4 92LF522-063 J AZ Clutc Ass’y Block [Tape 2]
208- 5 92LFF20D-12 J AN Belt,Main [Tape 2]
208- 6 92LF514-131 J AT Pinch Roller
208- 7 92LFF19S-31 J AL Belt,FF/REW [Tape 1]
208- 8 92LFF20B-13 J AN Belt,Main [Tape 1]
208- 9 92LF522-061 J AZ Clutc Ass’y Block [Tape 1]
208-10 92LFF19S-52 J AL Belt,FF/REW [Tape 2]
208-11 92LF513-895 J BD Head Plate Block [Tape 1]
209 LANGK0110AWFW J AE Bracket,Cassette Lock,Tape 1
210 LANGK0111AWFW J AE Bracket,Cassette Lock,Tape 2
211 LANGK0317AWFW J AF Bracket,Fan Support
212 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0174AWFW J AN Chassis,Main
214 LCHSM0155AWZZ J AS Chassis,Loading
215 LHLDM1018AWZZ J AE Stabilizer
216 LHLDZ1455AWZZ J AF Holder,CD Mechanism
217 LHLDZ1358AWZZ J AF Stabilizer Holder
218 LHLDZ1433AWZZ J AD Holder,Gear
219 LHLDZ1410AWZZ J AD Holder,FL Display
220 LHLDZ1412AWZZ J AC Holder,LED
221 MCAMP0010AWZZ J AE Gear,Can Upper
222 MCAMP0011AWZZ J AE Gear,Can Lower
223 MLEVP0109AWZZ J AB Lever,Cam Lock
224 MLEVP0110AWZZ J AB Lever,Switch A
225 MLEVP0111AWZZ J AB Lever,Switch B
226 MLEVP0112AWZZ J AB Turntable Actuator
227 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
228 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
229 MSPRC0033AWFJ J AB Spring,Friction
230 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
231 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
232 MSPRP0057AWFW J AC Spring,Tray Lock
233 MSPRP0068AWFW J AB Spring,Motor Gear
234 NFANP0001AWZZ J AD Rotary Fan
235 NGERH0152AWZZ J AC Gear,Turntable Drive
236 NGERH0153AWZZ J AC Gear,Drive
237 NGERW0020AWZZ J AC Gear,Center
238 NGERW0021AWZZ J AC Gear,Idler
239 NGERW0022AWZZ J AD Gear,Worm
240 NGERW0023AWZZ J AC Motor Gear
241 NTNT-0022AWZZ J AK Turntable
242 PCUSG0022AWZZ J AB Cushion,Leg
243 PMAGF0007AWZZ J AD Magnet
244 PRDAR0261AWFW J AT Heat Sink
1 245 QACCE0015AW00 J AK AC Power Supply Cord with
CNS805
246 QCNWN1860AWZZ J AC Lug Wire
1 247 QFSHD0001AWZZ J AB Holder,Fuse
248 92LCSPR1431C J AA Spring,Ring
249 92LMT0304302 J AB Plate,Metal
250 92LNBAND1318A J AA Nylon Band,80mm
251 92LPT0303002 J AB Roller
252 LANGK0359AWFW J AD Bracket,Heat Sink
253 HDECQ0964AWSA J AF Panel,Edge Light
254 LHLDZ1451AWZZ J AC Holder,Edge Light
255 JKNBK0095AWSA J AK Knob,Volume
257 PSHEP0119AWZZ J AD Sheet,Edge Light
258 MLEVF0117AWFW J AC Plate,Support
259 TLABS0354AWZZ J AC Label,Class 3A
260 PSLDM3015AWFW J AD Shield
601 XJBSD30P10000 J AA Screw,ø3×10mm
602 XEBSD30P12000 J AA Screw,ø3×12mm
603 LX-EZ0010AWFD J AA Screw,ø3×10mm
604 LX-JZ0044AWFF J AB Screw,ø3×10mm
605 LX-HZ0009AWFD J AC Screw,Special
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 92LSC0314WBZI J AB Screw,Special
608 XJBSD20P05000 J AA Screw,ø2×5mm
609 XHBSD40P08000 J AA Screw,ø4×8mm
610 XBBSD20P04000 J AA Screw,ø2×4mm
611 LX-JZ0010AFFD J AA Screw,ø3×10mm
612 XJSSD30P10000 J AA Screw,ø3×10mm
614 XHBSD30P06000 J AA Screw,ø3×6mm
615 LX-JZ0036AWFD J AB Screw,Special
616 LX-JZ0037AWFD J AB Screw,ø3×18mm
617 XEBSD30P10000 J AA Screw,ø3×10mm
618 XESSD30P10000 J AA Screw,ø3×10mm
619 92LSC0310RBZI J AB Screw,ø3×10mm
620 92LSC2608RBZI J AA Screw,ø2.6×8mm
ACCESSORIES/PACKING PARTS
1 QANTL0008AWZZ J AH AM Loop Antenna
2 SPAKA0431AWZZ J AL Packing Add.
3 SPAKC1561AWZZ J AV Packing Case
4 SPAKP0032AWZZ J AF Polyethylene Bag,Unit
5 92LBAG1460C1 J AB Polyethylene Bag,Accessories
6 TINSZ0895AWZZ J AP Operation Manual
8 TLABE0735AWZZ J AB Label,Bar Code
9 TLABZ0605AWZZ J AB Label,Saving Energy
10 TLABZ1322AWZZ J AC Label,Feature [Tape 2]
11 TLABZ1343AWZZ J AC Label,Feature [Tape 1]
12 92LFANT1535A J AF FM Antenna
13 RRMCG0361AWSA J AS Remote Control
GFTAT1017AWSA J AK Battery Lid,Remote Control
15 TLABZ0604AWZZ J AB Label,Energy
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~5 92LPWB4960MANS J –– Main/Display/Headphones/LED
A/LED B (Combined Ass’y)
1 PWB-B1,2 92LPWB4960PWRS J –– Power/Transformer
(Combined Ass’y)
PWB-C 92LPWB4896CDUS J –– CD Servo
PWB-D QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-E QPWBF0749AWZZ J AD CD Loading Motor (PWB Only)
PWB-F 92LF567-719 J –– Tape Mechanism
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
SPEAKER BOX PARTS
901 GBOXS2026AWSD J Speaker Box Ass’y,Right
901 GBOXS4026AWSD J Speaker Box Ass’y,Left
902 CPNLS1076AW01 J AX Front Panel Ass’y,Right
902 CPNLS1077AW01 J AX Front Panel Ass’y,Left
903 HPNLS1078AWSA J AW Side Panel,Right
– 5 –
CP-E700H
