Sharp CV-P10LJ

Technical Specifications
Sr
No
Parameter Unit Value
1 Model CV-P10LJ
Rated Voltage
V～
220-240
Rated Frequency Hz 50
2
Power
Supply
Phases 1
3 Cooling Capacity W 2930
4 Cooling Power Input W 1100
5 Cooling Power Current A 4.80
6 Rated Input W 1250
7 Rated Current A 5.80
8 Air Flow Volume(H/M/L) m
3
/h 350/260/180
9 Dehumidifying Volume L/h 1
10 EER W/W 2.66
11 Application Area m
2
14~20
12 Climate Type T1
13 Isolation I
14 Moisture Protection IP24
15
Permissible Excessive Operating Pressure
for the Discharge Side
MPa 3.8
16
Permissible Excessive Operating Pressure
for the Suction Side
MPa 1
17 Throttling Method Capillary
18 Fuse A 3.15
19 Operation Temp
℃ 16ºC～30ºC
20 Ambient Temp (Cooling)
℃ 10ºC～35ºC
21 Sound Pressure Level (H/M/L) dB (A) 56/54/52
22 Sound Power Level (H/M/L) dB (A) 66/65/62
23 Dimension (WXHXD) mm 500×830×450
24 Dimension of Carton Box (L/W/H) mm 578x532x862
25 Dimension of Package (L/W/H) mm 581x535x877
26 Net Weight kg 41
27 Gross Weight kg 48
E-24
