PART NAMES
1
Air Outlet
2
Vertical louvers
3
Horizontal louvers
4
POWER Button
5
Remote control signal
receiver window
6
OPERATION Lamp (red)
7
TIMER Lamp (orange)
8
MEGA COOL Lamp
(green)
9
PLASMACLUSTER
Lamp (blue)
0
Air inlet
REAR VIEW
NOTE: Actual unit might vary slightly from above illustration.
FRONT VIEW
q
Insect guard net
w
Window exhaust adapter
e
Remote control hook
r
Exhaust hose
t
Remote control hook
y
Air fi lter
u
Exhaust hose adapter B
i
Cover
o
Grille
p
Air inlet
a
Drainpipe and stopcock
s
Power
plug
Casters(4)
E-5
1
2
3
4
5
6
7
8
9
0
0
q
w
e
r
t
y
u
i
o
p
a
s
