TORQUE
MEASUREMENT
AT
PLAY,
FF
AND
REWIND
MODES
(Refer
to
Figure
18)
1.
Mount
a
torque
measuring
reel
on
the
reel
support
(that
is,
it
is
placed
on
the
take-up
turntable
support
at
PLAY/
REWIND
mode
while
on
the
supply
turntable
support
at
REWIND
mode).
2.
Then
gradually
release
the
tension
gauge
and
read
it
when
the
rotational
speed
of
the
reel
support
becomes
almost
constant.
3.
Measured
torques
at
each
mode
should
be
as
tabulated
below.
Note:When
the
take-up
turntable
support
is
stopped
at
PLAY
mode,
there
should
be
no
slip
between
the
take-up
turntable
support
and
take-up
slip
roller
and/or
between
the
drive
belt
and
take-up
slip
roller.
TURN
TABLE
MEASURING
—__20(25/32")
REEL
TENSION
GAUGE
MEASURED
TORQUE
35~
60
gr.cm
70
~
100
gr.cm
70
~
100
gr.cm
REWIND
Figure
18
=
GAP
ADJUSTMENT
BETWEEN
MOTOR
SWITCH
AND
BRAKE
LEVER
(Refer
to
Figure
19)
1.
Under
each
of
PLAY,
FF,
and
REWIND
modes,
make
ascertain
that
the
motor
switch
(SW504)
is
turned
“ON”
without
fail.
2.
When
the
motor
is
in
a
stop,
check
that
the
gap
(A)
between
the
brake
lever
and
the
motor
switch
(SW504)
is
2
mm
to
3
mm.
3.
If
the
steps
1
and
2
above
are
still
insufficient
for
the
adjustment,
the
gap
can
be
adjusted
by
positionally
changing
the
two
soldered
terminals
of
motor
switch
(SW504)
located
at
the
motor
PWB
with
use
of
a
soldering
iron.
MOTOR
SWITCH
(SW504)
__
BRAKE
LEVER
OPERATION
CHECK
OF
PAUSE
MECHANISM
(Refer
to
Figure
42,
Page
29)
Set
the
unit
in
PLAY
mode
by
pushing
the
key
given
a
mark
(
<q
).
Then
slowly
push
the
PAUSE
key
and
make
ascertain
that
the
take-up
idler
(028)
and
the
pinch
roller
(090)
come
off
respectively
from
the
take-up
turntable
support
(081)
and
the
flywheel
shaft
almost
at
the
same
time
and
check
that
each
of
the
two
gaps
thus
produced
is
about
0.5
mm.
TURNTABLE
Figure
19
@
ADJUSTMENT
OF
PLUNGER
SETTING
POSITION
(Refer
to
Figure
20)
1.
Under
FF
mode,
loosen
the
plunger
retaining
screw,
hold
up
the
part
@)
of
the
plunger
by
hand
and
while
keeping
the
plunger
in
contact
with
the
lock
shaft,
retighten
the
plunger
retaining
screw.
2.
After
the
step
1,
make
sure
of
the
following.
«Check
that
each
of
the
PLAY,
FF
(CUE),
REWIND
(REVIEW)
keys
can
be
locked
smoothly.
-
Check
that
the
FWD-APSS
key
and
REV-APSS
key
can
be
locked
smoothly
and
they
further
be
released
when
the
plunger
operates.
-
Check
that
the
plunger
can
start
to
operate
smoothly
when
the
STOP
key
is
pushed
to
release
the
APSS
keys.
3.
After
the
step
2,
the
adjustments
are
not
yet
sufficient,
again
carry
out
the
step
1.
PLUNGER
ADJUST
SCREW
LOCK
SHAFT
PLUNGER
_
Figure
20
