Sharp GX-CD130C

PRICE
RANK
DESCRIPTIONNO.
PART CODE
★
NO. PARTS CODE
PRICE
RANK
★
DESCRIPTION
GX-CD30/30C/130/130C
SW775 QSW-K0003AWZZ J AD Switch,Key Type [CD-Pause]
DECK MECHANISM PARTS
1 92LM-ANG1658A J AC Joint Bracket,Mechanism
3 92LM-BELT1651B J AB FR Belt
4 92LMBELT1658A1 J AC Drive Belt [Tape 1]
5 92LMBELT1658B1 J AC Drive Belt [Tape 2]
10 92LM-CSPR667J J AA Spring,Latch Plate
12 92LM-CSPR1651F J AA Spring,Back Tention
13 92LM-EH1658A J AG Head,Erase
14 92LM-ESPR1651A J AA Spring,Lock Plate
15 92LM-ESPR1651B J AA Spring,Holder Lock Lever
17 92LM-FRRA1651A J AF FR Roller Ass’y
18 92LM-FWA1651A J AG Flywheel Ass’y [Tape 2]
19 92LM-FWA1658A J AG Flywheel Ass’y [Tape 1]
20 92LM-GEAR1651C J AA Gear,FF
21 92LM-HPLT1746A J AC Plate,Head
22 92LM-ICAM1651A J AB Cam,Idler
23 92LM-ILA1651A J AB Idler Lever Ass’y
24 92LM-LEV1651G1 J AC Lever,Main Lock
25 92LM-LEV1651I J AA Lever,AS Killer
27 92LM-LEV1651K J AA Lever,Eject Joint
28 92LM-LEV1651L J AB Lever,Erase Prevention
29 92LM-LEV1658A1 J AB Lever,Record
30 92LM-LEV1658B J AA Lever,Play
31 92LM-LEV1658C J AA Lever,Rewind
32 92LM-LEV1658D J AB Lever,FF
33 92LM-LEV1658E J AB Lever,Stop
35 92LM-LEV1658H J AB Lever,Holder Lock
38 92LM-LGA1746A J AF Lever Guide Ass’y
40 92LM-MCA1654A J AK Main Chassis Ass’y [Tape 2]
42 MSPRP0492AFFW J AA Spring,Cassette
45 92LM-PRA1651A J AE Pinch Roller Ass’y
46 92LM-REL1651B J AB Supply Reel
47 92LM-RPH1746A J AM Head,Record/Playback
50 92LM-TSPR1746A J AA Spring,Pinch Roller
51 92LM-TSPR1651B J AA Spring,Operate Lever
52 92LM-TSPR1651C J AA Spring,Record Lever
53 92LM-TSPR1651D J AA Spring,Idler Lever
55 92LM-TSPR1651F J AA Spring,AS Killer Lever
56 92LMTURA1651A1 J AF Take-up Reel Ass’y
58 92LM-TSPR1651G J AA Spring,Pause Stop Lever
64 92L1R5WC3R8R5P J AA Washer,ø1.5×ø3.8×0.5mm
66 92L1R8WC3R4R5P J AA Washer,ø1.8×ø3.4×0.5mm
67 92L2R3W6R5P J AA Washer,ø2.3×ø6×0.5mm
69 92L1R2WC4-R5P J AA Washer,ø1.2×ø4×0.5mm
70 92L3R6W6-R5P J AA Washer,ø3.6×ø6×0.5mm
71 92LS2R7W6R4R5L J AA Washer,ø2.7×ø6.4×0.5mm
72 92LM-MCA1858A J AH Main Chassis Ass’y [Tape 1]
501 92LS2R6S1746A J AA Motor Screw,ø2.6mm
504 92L2BTS+5BZ J AA Screw,ø2×5mm
505 92L2BTS+7BZ J AA Screw,ø2×7mm
506 92L2TTS+3BZ J AA Screw,ø2×3mm
508 92L2TTS+4BZ J AA Screw,ø2×4mm
509 92L2TTS+4PZ J AA Screw,ø2×4mm
511 92L2BTS+5PZ J AA Screw,ø2×5mm
M601 92LMTR1746AASY J AP Motor with Pulley [Tape]
SW605 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 1 Main]
SW606 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 2 Main]
SW607 92LM-SW1658A J AB Switch,Leaf Type [Tape 1/2
Selector]
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 PCUSG0427AFSC J AC Cushion
î306 RCTRH8151AFZZ J BG Pickup Unit Ass’y
306- 1 ———— — Pickup Unit (Not Replacement
Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
307 PCOVP1001AWSA J AE Mechanism Cover
701 92L2R6S+6CZ J AB Screw,ø2.6×6mm
702 92L2TTS+5BB J AB Screw,ø2×5mm
703 92L2S+3PZ J AA Screw,ø2×3mm
704 92L1R5WC3R8R25 J AA Washer,ø1.5×ø3.8×0.25mm
M701 92LMTR1906CASY J AS Motor with Chassis [Spin]
R834 VRD-MN2BD102J J AA 1 kohm,1/8W
R835 VRD-MN2BD471J J AA 470 ohms,1/8W
R836,837 VRD-MN2BD473J J AA 47 kohms,1/8W
R838 VRD-MN2BD333J J AA 33 kohms,1/8W
R839,840 VRD-MN2BD223J J AA 22 kohms,1/8W
R842 VRD-ST2EE220J J AA 22 ohms,1/4W
R849 VRD-MN2BD104J J AA 100 kohm,1/8W
R856 VRD-MN2BD122J J AA 1.2 kohms,1/8W
R857 VRD-MN2BD273J J AA 27 kohms,1/8W
R858 VRD-MN2BD681J J AA 680 ohms,1/8W
R860 VRD-MN2BD102J J AA 1 kohm,1/8W
R871 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R873,874 VRD-MN2BD101J J AA 100 ohm,1/8W
R875,876 VRD-MN2BD103J J AA 10 kohm,1/8W
R877 VRD-ST2EE221J J AA 220 ohms,1/4W
R878 VRD-MN2BD101J J AA 100 ohm,1/8W
R880 VRD-MN2BD101J J AA 100 ohm,1/8W
OTHER CIRCUITRY PARTS
BI651/CNS651 QCNWN0602AWZZ J AG Connector Ass’y,2-2Pin
BI801/CNS801 QCNWN0605AWZZ J AL Connector Ass’y,8-8Pin
BI802/CNS802 QCNWN0606AWZZ J AH Connector Ass’y,5-5Pin
BI803/CNS803 QCNWN0607AWZZ J AH Connector Ass’y,6-6Pin
CNP1 92LCONE6P52287 J AC Plug,6Pin
CNP201 92LCONE3P53253 J AB Plug,3Pin
CNP202 92LCONE5P53253 J AB Plug,5Pin
CNP204 QCNCW027HAWZZ J AC Plug,8Pin
CNP552 QTANA0404AWZZ J AF Terminal,Ext.Speaker
CNP602 QCNCW012LAWZZ J AE Plug,11Pin
CNP603 92LCONE3P52287 J AC Plug,3Pin
CNP651 QCNCM742BAFZZ J AA Plug,2Pin
CNP652 92LCONE4P52287 J AC Plug,4Pin
CNP803 QCNCM932FAFZZ J AC Plug,6Pin
CNP851 QCNCW026EAWZZ J AE Plug,5Pin
CNP852 QCNCW026MAWZZ J AG Plug,12Pin
CNS201 QCNWN0595AWZZ J AH Connector Ass’y,3Pin
CNS202 QCNWN0596AWZZ J AL Connector Ass’y,5Pin
CNS204 QCNWN0600AWZZ J AH Connector Ass’y,8Pin
CNS653 QCNWN0487AWZZ J AB Connector Ass’y,1Pin
CNW2 QCNWN0716AWZZ J AD Tip with Lead
FW1 QCNWN0687AWZZ J AE Flat Cable,6Pin
FW602 QCNWN0601AWZZ J AG Flat Cable,11Pin
FW603 QCNWN0717AWZZ J AD Flat Cable,2Pin
FW651 QCNWN0594AWZZ J AD Flat Cable,2Pin
FW652 QCNWN0718AWZZ J AD Flat Cable,4Pin
FW772 QCNWN0603AWZZ J AC Flat Cable,2Pin
FW851 QCNWN0689AWZZ J AE Flat Cable,5Pin
FW852 QCNWN0604AWZZ J AH Flat Cable,12Pin
J551 QJAKM0004AWZZ J AK Jack,Headphones
LCD771 RV-LX0018AWZZ J AQ LCD
M601 92LMTR1746AASY J AP Motor with Pulley [Tape]
M701 92LMTR1906CASY J AS Motor with Chassis [Spin]
M702 92LMTR1854BASY J AP Motor with Gear [Slide]
RX771 VHLSPS4201C-1 J AN Remote Sensor,LSPS4201C
[130/130C Only]
îSO651 QSOCA0201AWZZ J AL Socket,AC Power Supply Input
[130/30]
îSO651 QSOCA0203AWZZ J AL Socket,AC Power Supply Input
[130C/30C]
SP1,2 VSP0010PBR26A J AP Woofer
SP3,4 RALMB0101AFZZ J AB Tweeter
SW201 QSW-S0018AWZZ J AG Switch,Slide Type [Record/
Playback]
SW351 QSW-S0024AWZZ J AE Switch,Slide Type [Beat Cancel]
SW500 QSW-S0026AWZZ J AF Switch,Slide Type [X-BASS] [130/
130C Only]
SW501 QSW-S0022AWZZ J AK Switch,Slide Type [Power/
Function]
SW605 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 1 Main]
SW606 QSW-F0340AFZZ J AE Switch,Leaf Type [Tape 2 Main]
SW607 92LM-SW1658A J AB Switch,Leaf Type [Tape 1/2
Selector]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW761 QSW-P0004AWZZ J AE Switch,Push Type [CD Lid Open/
Close]
SW771 QSW-K0003AWZZ J AD Switch,Key Type [CD-Play/
Repeat]
SW772 QSW-K0003AWZZ J AD Switch,Key Type [CD-Stop]
SW773 QSW-K0003AWZZ J AD Switch,Key Type [CD-Up/Cue]
SW774 QSW-K0003AWZZ J AD Switch,Key Type [CD-Down/
Review]
– 3 –
