Sharp GX-CD130C

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
★
NO. PART CODE
PRICE
RANK
★
DESCRIPTION
GX-CD30/30C/130/130C
253 TLABH0042AWSA J AE Cassette Label,Tape 2
[130/130C]
253 TLABH0042AWSB J AE Cassette Label,Tape 2 [30/30C]
601 LX-CZ0011AFFD J AA Screw,ø3×65mm
602 XEBSD30P12000 J AA Screw,ø3×12mm
603 XEBSD30P20000L J AB Screw,ø3×20mm
604 XHSSF30P08000 J AA Screw,ø3×8mm
605 XJSSF30P10000 J AA Screw,ø3×10mm
606 XEBSD30P10000 J AA Screw,ø3×10mm
607 XWHSD32-15140 J AA Washer,ø3.2×ø14×1.0mm
608 XBPSD26P06J00 J AA Screw,ø2.6×6mm
610 XWSSJ30-07000 J AA Washer,ø3×0.7mm
611 XEBSD26P10000 J AA Screw,ø2.6×10mm
612 XWHSD28-08120 J AB Screw,ø2.8×ø12×0.8mm
613 XCBSD30P08000 J AA Screw,ø3×8mm
614 XHBSD20P03000 J AA Screw,ø2×3mm
615 XWHSD32-08170 J AA Washer,ø3.2×ø17×1.0mm
616 XEBSD30P08000 J AA Screw,ø3×8mm
617 LX-EZ0002AWFD J AA Screw,ø3×40mm
618 XJSSD30P10000 J AA Screw,ø3×10mm
619 XEBSD30P12000 J AA Screw,ø3×12mm
SPEAKER BOX PARTS
701 92LSCAB2237AS1 J AU Front Cabinet Ass’y,Speaker,Left
[30/30C]
701 92LSCAB2238AS1 J AZ Front Cabinet Ass’y,Speaker,Left
[130/130C]
702 92LSCAB2237AS2 J AU Front Cabinet Ass’y,Speaker,
Right [30/30C]
702 92LSCAB2238AS2 J AZ Front Cabinet Ass’y,Speaker,
Right [130/130C]
703 GCABB1130AWSA J AY Rear Cabinet,Left
704 GCABB1131AWSA J AY Rear Cabinet,Right
705 QCNWN0597AWZZ J AE Speaker Wire
901 XEBSD30P10000 J AA Screw,ø3×10mm
902 XEBSD30P20000 J AA Screw,ø3×20mm
PACKING PARTS [FOR GX-CD30C/130C]
SPAKA0093AWZZ J AH Packing Add.,Unit (Left/Right)
SPAKA0094AWZZ J AK Packing Add.,Speaker,Top/
Bottom
SPAKC0347AWZZ J AP Packing Case [30C]
SPAKC0348AWZZ J AP Packing Case [130C]
SSAKH0017AWZZ J AC Polyethylene Bag,Unit
92LBAG1607A1 J AB Polyethylene Bag,Speaker
ACCESSORIES
TINSE0115AWZZ J AG Operation Manual [130/30]
TINSK0040AWZZ J AH Operation Manual [130C/30C]
î 92LCORD-1651A J AM AC Power Supply Cord
[130/30]
î 92LCORD-1207A J AM AC Power Supply Cord
[130C/30C]
92LPOPLABEL001 J AR Feature Label,Speaker [130C]
92LPOPLABEL004 J AE Feature Label,Speaker [30C]
RRMCG0052AWSA J BB Remote Control [130/130C Only]
GFTAB1016AWSA J Battery Lid,Remote Control
[130/130C Only]
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1ç5 92LPWB2237MANS J — Main/Display/Power/Terminal/
Switch [30/30C]
PWB-A1ç5 92LPWB2238MANS J — Main/Display/Power/Terminal/
Switch [130/130C]
PWB-B 92LPWB2238TUNS J — Tuner
PWB-C 92LPWB2238DEKS J — Deck
PWB-D 92LPWB2238CDUS J — CD Servo
PWB-E QPWBF0027AWZZ J AD CD Motor (PWB Only)
– 4 –
M702 92LMTR1854BASY J AP Motor with Gear [Slide]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 92LCAB2237AS1 J AV Front Cabinet Ass’y [30/30C]
201 92LCAB2238AS1 J BD Front Cabinet Ass’y [130/130C]
201- 1 ———— — Front Cabinet (Not Replacement
Item)
202 GCABC1129AWSA J AX Top Cabinet
203 GCABB1129AWSA J AZ Rear Cabinet [130]
203 GCABB1140AWSA J AZ Rear Cabinet [130C/30C]
203 GCABB1143AWSA J AS Rear Cabinet [30]
204 92LBSPR1401A J AC Spring,Battery,+/-
205 GFTAB1001AWSA J AE Battery,Lid
206 92LMEC2237CTS1 J AK Cassette Holder Ass’y,Tape 1
[30/30C]
206 92LMEC2238CTS1 J AP Cassette Holder Ass’y,Tape 1
[130/130C]
206- 1 ———— — Cassette Holder,Tape 1 (Not
Replacement Item)
206- 2 HPNLH1063AWSA J AE Panel,Cassette,Tape 1
207 92LMEC2237CTS2 J AK Cassette Holder Ass’y,Tape 2
[30/30C]
207 92LMEC2238CTS2 J AP Cassette Holder Ass’y,Tape 2
[130/130C]
207- 1 ———— — Cassette Holder,Tape 2 (Not
Replacement Item)
207- 2 HPNLH1064AWSA J AE Panel,Cassette,Tape 2
208 92LMAG2238AS1 J AN Magnet Ass’y
209 MLIFP0003AWZZ J AE Damper [CD Lid]
210 HPNLD1003AWSA J AG Panel,Dial
211 92LPNL2237AS1 J AK Decoration Panel Ass’y [30/30C]
211 92LPNL2238AS1 J AQ Decoration Panel Ass’y
[130/130C]
211- 1 ———— — Decoration Panel (Not Replace
ment Item)
211- 2 HPNLH1065AWSA J AF Panel,LCD [130/130C]
211- 2 HPNLH1066AWSA J AD Panel,LCD [30/30C]
213 92LKNOB1596C J AA Knob,Function/Power
214 JKNBK0032AWSA J AE Knob,Volume
215 JKNBK0033AWSA J AE Knob,Tone
216 92LDAMPER1651A J AD Damper [Cassette Holder]
217 92LCSPR1596A J AA Spring,Cassette Up
218 LANGK0044AWZZ J AD Bracket,Front Cabinet
219 PSPAZ0010AWZZ J AG Joint Boss
220 LANGK0041AWZZ J AF Bracket,Cassette Button
221 92LFELT666B J AA Felt
222 JKNBZ0190AWSA J AD Button,Record [Tape 1]
223 JKNBZ0191AWSA J AD Button,Play [Tape 1]
224 JKNBZ0192AWSA J AD Button,Rewind [Tape 1]
225 JKNBZ0193AWSA J AD Button,FF [Tape 1]
226 JKNBZ0194AWSA J AD Button,Stop [Tape 1]
227 JKNBZ0195AWSA J AE Button,Play [Tape 2]
228 JKNBZ0196AWSA J AE Button,Stop [Tape 2]
229 HSSND0008AWSA J AE Dial Pointer
230 LHLDZ1093AWZZ J AH Tuner Frame
231 JKNBZ0189AWSA J AG Knob,Tuning
232 92LWHEL1569A J AE Dial Wheel
233 92LATML1455A J AB Antenna Terminal
234 GDORT0011AWSA J AP CD Lid
235 MSPRD0067AWZZ J AG Spring,CD Lid Up
236 QANTR0006AWZZ J AQ Rod Antenna
237 92LHNDL2238AS1 J AQ Handle Ass’y
239 JKNBZ0119AWSC J AE Knob,CD Eject
240 JKNBZ0188AWSA J AF Knob,CD Control
241 92LRDAT1524A J AE Heat Sink
243 TSPC-0357AWZZ J AE Label,Specifications [30C]
243 TSPC-0358AWZZ J AE Label,Specifications [130C]
244 92LCAUT1459C J AA Caution,Battery [130C/30C]
245 LANGK0042AWZZ J AD Bracket,Deck PWB
246 LANGK0043AWZZ J AC Bracket,Tuner PWB
247 92LM-LEV1746A J AB Spring,Record
248 LHLDZ1094AWZZ J AE Holder,LCD
249 92LBSPR1595C J AB Spring,Battery,-
250 ———— — Spacer,PWB Washer (Not
Replacement Item)
251 92LCUSN1585A J AA Leg Cushion
252 TLABH0041AWSA J AE Cassette Label,Tape 1
[130/130C]
252 TLABH0041AWSB J AE Cassette Label,Tape 1 [30/30C]
