KB-6015KS
KB-6015KK
KB-6015KW
MICROWAVE DRAWER PARTS LIST
Note: The parts marked “
ΔΔ
ΔΔ
Δ” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
3- 1 RTRN-B084MRE0 M Transformer 1 BE
3- 2 RV-MZA288WRE0 M Magnetron 1 BK
3- 3 FDTCTA234WRKZ M Sensor assy 1 AP
3- 4 FFS-BA018/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
3- 5 XOTSE40P08000 M Screw 1 AA
3- 6 TCAUAB050MRR0 M Monitor caution label 2 AD
3- 7 LHLD-B028MRF0A M Power supply unit holder 1 AH
3- 8 DPWBFB137MRU0 M Power supply 2 BD
3- 9 LANGTB073MRP0 M Oven lamp angle 1 AF
3-10 LX-CZ0052WRE0 M Screw/washer 6 AA
3-11 GCABDB006MRP0 M Back plate 1 BB
3-12 PDUC-B141MRP0 M Mag duct 1 AE
3-13 PDUC-B142MRP0 M Sensor duct 1 AK
3-14 PDUC-B004MRP0 M Exhaust duct A 1 AK
3-15 PDUC-B148MRP0 M Exhaust duct B 1 AF
3-16 FCOVPB002MRY0 M Stir cover assy 1 AM
3-17 PCLICB003MRE0 M Canoe clip 3 AB
3-18 MSLIFB001/KIT M Slide rail 3 AU
3-19 LANGTB120MRP0 M Door support angle A 2 AK
3-20 LANGTB113MRP0 M Door support angle B 1 AK
3-21 GCOVHB051MRF0 M Door support cover 2 AB
3-22 PSKR-B018MRP0 M Magnetron air guide 1 AC
3-23 PFILWB005MRP0 M Lamp filter 1 AB
3-24 LANGTB076MRP0 M Partition angle 1 AK
3-25 FC-QZB048MRK0 M HVC assy 1 AP
3-26 LBNDKB007MRP0 M HVC band 1 AB
3-27 XCBSD30P08000 M Screw 3 AA
3-28 XOTSE40P12000 M Screw 79 AA
3-29 LANGTB114MRP0 M Partition angle L 1 AK
3-30 LANGQA581WRPZ M Noise unit angle 1 AD
3-31 XJTSD40P16000 M Screw 4 AA
3-32 XEPSD30P10XS0 M Power unit assy screw 2 AA
3-33 DDORFB098MRK0 M Door assy [KB6015KS] 1 BD
3-33 DDORFB102MRK0 M Door assy [KB6015KK] 1 BD
3-33 DDORFB103MRK0 M Door assy [KB6015KW] 1 BD
3-34 PSHEPB184MRE0 M Sealer film 1 AQ
3-35 FFAN-B008MRK0 M Stirrer fan assy 1 AK
3-36 FANGTB010MRK0 M Latch angle assy R 1 AH
3-37 FANGTB011MRK0 M Latch angle assy L 1 AH
3-38 GCABUB146MRP0 M Side cabinet L 1 AY
3-39 GCABUB145MRP0 M Side cabinet R 1 AY
3-40 PCOVPB143MRP0 M Air cover 1 AE
3-41 LX-NZB006MRE0 M Cap nut 6 AA
3-42 XHTSD40P08RV0 M Screw 4 AA
3-43 TCAUKB001MRR0 M Stirrer cover cleaning label 1 AA
3-44 FMOTEA499WRKZ M Fan motor 1 AZ
3-45 LANGTB077MRP0 M Fan motor angle 1 AG
3-46 RTHM-A135WRZZ M Thermal cut-out 2 AD
3-47 FW-VZB267MRE0 M Harness assy 1 BE
3-48 PHOK-A079WRF0 M Latch hook R 1 AH
3-49 PCUSGB066MRP0 M Cushion 1 AB
3-50 PHOK-A080WRF0 M Latch hook L 1 AF
3-51 MLEVPA214WRF0 M Switch lever L 1 AK
3-52 QSW-MA---WRE0 M Monitor switch - must replace by assy. (3-4) 1 AE
3-53 QSW-MA085WRE0 M Switch 4 AE
3-54 QSOCLB010MRE0 M Lamp socket 1 AG
3-55 XEPSD30P10XS0 M Screw 4 AA
3-56 FPWBFA380WRKZ M Noise filter unit 1 AM
3-57 RLMPTA071WRE0 M Oven lamp 1 AF
3-58 JHNDPB058MRT0 M Door handle [KB6015KS] 1 BC
3-58 JHNDPB059MRT0 M Door handle [KB6015KK] 1 BC
3-58 JHNDPB060MRT0 M Door handle [KB6015KW] 1 BC
ΔΔ
ΔΔ
Δ
*
To Next Page
