8
Part Names of Main Unit
Controls
Note:
Note:
• TV/VIDEO, CH(
)/( ), Volume (–)/(+) and MENU on the main unit have the same functions as the same buttons on the remote control.
Fundamentally, this operation manual provides a description based on operation using the remote control.
CH
MENU
TV/VIDEO
Volume (–)/(+)
POWER/STANDBY indicator
A green indicator lights when the power is on and a red
indicator lights when in the standby mode (the indicator will
not light when the main power is off).
Remote sensor window
Remote sensor indicator
A red indicator blinks when the TV set receives the
remote control signal.
Upper control panel
CH ( )/( )
MENU
TV/VIDEO
(MAIN POWER)
Speaker
To change the vertical angle of
the LCD TV set, tilt the screen
up to 5 degrees forward or 10
degrees backward. The TV set
can also be rotated 25 degrees
to right and left. Please adjust
the angle so that the TV set can
be watched most comfortably.
(See How to adjust the angle
on page 9.)
Speaker
