Sharp LC-32CFE6242E Service Manual

23
LC-32CHE5221E
www.sharp.eu
DISPLAY
Diagonal screen size cm / inch 81/32
Panel resolution 1366x768
Active motion 200
Backlight D-LED
Brightness (cd/m²) 300
Dynamic contrast 1 000 000:1
AUDIO SYSTEM
Speaker 2
Audio Power 2x8W (8 ohm)
Sound System B/G, D/K, I, L
NICAM/A2
Sound Settings Treble / Bass
Audio decoder Dolby Digital/Digital+/DTS 2.0
Audio enhancement solution DTS TruSurround™
TUNER
TV system ATV PAL, SECAM
DTV DVB-T/T2/C+MPEG4
FUNCTION
USB Video AVI/MKV/WMV/ASF/MP4/M4v/RM/
RMVB/VOB/TS/M2TS/MPG/FLV/SWF
USB Music MP3, M4a, WMA, AAC, AC3, EAC3,
LPCM, OGG
USB Photo JPG, JPEG, BMP, PNG
PVR Ready with timeshift YES (FAT32 only)
USB Software Update YES
USB le system FAT16/FAT32/NTFS
HDMI-CEC YES
HDMI-ARC YES (HDMI2)
Digital Programme List YES
CONNECTORS
HDMI-in YES (3x)
USB YES (2x)
SCART YES
RJ 45 YES
Common interface / CI+ YES
Antenna In (RF) YES
Mini Component/YPbPr YES
Mini AV Composite input + Audio In YES
PC Input (D-sub15 pin) YES
PC Audio Input YES
Audio out / Headphone Jack YES
Digital Optical Audio Output YES
OTHERS
Power Requirements 220-240V ±20% / 50Hz
Safety Logo Certication CE (EMC), CB (Safety),
ErP (Energy) etc
ErP Compliant A+ Class
Power Consumption
(ecomode/standard/max) 31/45/70W
Power Consumption (Standby Mode) <0.50 W
VESA standard (mm) 400 x 200
EAN 4974019857985
Net size with stand (W x H x D in mm): 728,3 x 461,3 x 168,0
Net size without stand (W x H x D in mm): 728,3 x 425,9 x 68,3
Net weight with stand (kg) 4,5
Net weight without stand (kg) 4,3
The LC-32CHE5221E is an Full HD D-LED TV
with exceptional picture quality.
With 3 HDMI ports, you can connect to your Satellite box, games console, Blu-Ray player or any other HDMI
equipped device. Its USB port allows you to enjoy your music, movies or photos from a USB memory key.
Product Fiche
Supplier trademark Sharp LC-32CHE5221E
Energy class A+
Screen size 81 cm / 32 inches
Power consumption 31.0 W
Annual energy consumption* 45 kWh
Standby power consumption <0.50 W
O mode power consumption Not applicable
Screen resolution 1366 (H) × 768 (V)
* - Energy consumption XYZ kWh per year, based on the power consumption
of the television operating 4 hours per day for 365 days. The actual energy
consumption will depend on how television is used.
Sharp believe that seeing is believing /This is Why our
latest LED TVs feature innovative technologies for the most
vibrant, colourful picture yet.
LC-32CHE5221E
SCREEN SIZE 81 cm (32”)
HD TUNER DVB-T/T2/C
3 HDMI INPUTS
USB FOR MULTIMEDIA
PLAYBACK AND RECORDING
200
ACE PRO

Sharp LC-32CFE6242E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	32 \
Display brightness	280 cd/m²
Display technology	LED
Native aspect ratio	16:9
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	1000000:1
Display diagonal (metric)	81 cm
Motion interpolation technology	Active Motion 400
3D	No
Voltage tolerance	20 %
Supported file systems	FAT16, FAT32, NTFS
Annual energy consumption	45 kWh
Audio system	B/G, D/K, I, L NICAM/A2
Audio decoders	Dolby Digital, DTS 2.0, DTS TruSurround, Dolby Digital Plus
RMS rated power	8 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
DVI port	-
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	Aquos Net+
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Video apps	YouTube
Lifestyle apps	Facebook, Twitter
Audio formats supported	AAC, AC3, EAC3, M4A, MP3, WMA
Image formats supported	BMP, JPEG XR, JPG, PNG
Video formats supported	ASF, AVI, FLV, M2TS, M4V, MKV, MP4, MPG, RM, RMVB, SWF, TS, VOB, WMV
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (max)	70 W
Power consumption (standby)	0.5 W
Power consumption (typical)	45 W
Power consumption (PowerSave)	31 W
Certification	CE (EMC), CB (Safety), ErP (Energy)
Product color	Black
Panel mounting interface	400 x 200 mm

Weight and Dimensions

Depth (with stand)	168 mm
Height (with stand)	461.3 mm
Weight (with stand)	4500 g
Depth (without stand)	68.3 mm
Width (without stand)	728.3 mm
Height (without stand)	425.9 mm
Weight (without stand)	4300 g
