Attaching/detaching the stand
ATTACHING THE STAND
Attaching the stand/feet
To complete the stand/feet installation you will require a cross head screw driver.
Screws that are included.
4 x
L
R
4 x
L
R
1
2
(fi g.1) Place the TV set on a fl at and clean surface with the panel facing downwards to avoid
damage, then fi x the stand/feet shown. The feet are marked L (left) and R (right).
(fi g.2) Secure the stand/feet to the underside of the TV set using the 4 screws provided.
Detaching the stand
Remove the screws highlighted then remove the stand/feet from the underside of the TV set.
