EN

What is included in the box
Supply of this TV includes following parts:
• 1x TV • 1x RF cable
• 1x Remote control • 1x TV stand installation packet
• 2x AAA batteries • 1x User guide
• 1x mini component adapter
cable*
• 1x mini composite adapter
cable*
* - only for 32" models

Attaching the Stand
Please follow the instructions on last page of this user manual.

Wall mounting the TV
1. Remove the four screws that are supplied in the wall mounting holes.
2. The wall mount can now be easily attached to the mounting holes on
the rear of the TV.
3. Install the wall mounting bracket to the television as advised by the
bracket manufacturer.

Getting started - initial set up
1. Using the RF cable supplied, connect the TV to the TV Aerial wall
socket.
2. For connecting to the Internet with a wired connection connect a
Cat 5/Ethernet cable (not included) from the TV to your broadband
modem/router.
3. Insert the batteries supplied into the Remote control.
Connect the power cable to the Electrical outlet. The TV should power
on automatically once the TV is connected to the mains.
a) If the TV turns on automatically and the  rst time installation
screen appears but the TV does not react to remote control, press
and hold the YELLOW and BLUE buttons on the remote control for a
few seconds. The power light will blink 5 times to con rm the TV and
remote control are paired.
b) If the TV does not automatically turn on you will need to turn the
TV on by pressing TV control stick located on the lower left corner of
back side of the TV. Once switched on, press and hold the TV control
stick on the TV set, this will prompt the ‘pairing menu’ to appear, scroll
through and highlight ‘Pair your remote’ by pressing the control stick
up/down (scroll up/down function in the menu) then press the control
stick (OK function in the menu) to con rm your selection. Then with
the remote control, press and hold the YELLOW and BLUE buttons for
a few seconds, the power light will blink 5 times to con rm the TV and
remote control are paired.
4. You will be now welcomed with the First Time Installation screen.
If it does not appear, on the remote control, please press [MENU] then
8-8-8-8 and the menu will appear.
If you wish to make changes to any of the default settings, use the
scroll ▲/▼/◄/► buttons. To exit this menu at anytime, press [EXIT]
button.
5. Please set desired settings in FIRST TIME INSTALLATION screen.
DVB Antenna - You can choose between Terrestrial (DVB-T/T2), Cable
(DVB-C) or Satellite (DVB-S/S2)*.
Language - Set the TV Menu language.
Country - Set the desired country.
Tunning Mode - Choose if you want to tune only Digital (DTV)
Analogue (ATV) or both Digital and Analogue (DTV + ATV)
Environment - Select the location of TV.
For home use, please select Home Mode.
For shop demonstration mode, set Store Mode.
Sorting by LCN - Set LCN to ON if you want to arrange channels by
provider preferences (only applies to DVB-T and DVB-C channels).
6. Press [OK] button to start the tuning process.
7. Optional channel presets DVB-C:
Keep all default settings as recommended.
If DVB-C channels are not found, contact your network provider for the
valid "Network ID". Then perform anew search. Press the [MENU], select
"Network ID" and enter the network ID.
8. Optional channel presets DVB-S2*: Select "Satellite" in the "DVB
Antenna" in the menu for the optional channel presets. Here you can
choose between the various satellites. Since selection completed, then
the channel list of the exact satellite will be available to be imported
into your TV system.
Con rm with [OK] button on the remote control, to start scanning.
TIP: If you are missing channels, the reason for this is likely to be signal
strength, you should consider connecting signal booster and re-tuning the TV.
* - Available only for TVs with DVB-S tuner

Remote control
Radio controlled remote control - No more aiming in the TV direction!
Refer to remote control picture on the second page of this user
manual.
1.
STANDBY – Switch on TV when in standby or vice versa.
2. SOURCE – To display the input/source menu.
3.
MUTE – Mute the sound or vice versa.
4. 0 – 9 – to select aTV channel directly.
5. MEDIA – Switch to USB source.
6. RADIO – Switch to Digital radio stations.
7. SLEEP – Press repeatedly to cycle through the sleep options.
8. TV GUIDE – Opens the 7 Day TV Guide (Digital mode).
9.
– To return to the previous channel viewed.
10. ASPECT – To switch the screen between the di erent picture formats.
11. VOL ▲/▼ – To increase/decrease the sound level.
12. TV – Switch to digital TV source.
13. INFO – Press once for now/next channel information. Press twice for
programme information about current programme.
14. CH ▲/▼ – To increase or decrease the channel being watched.
15. SUBTITLE – To switch the dialogue at the bottom of the screen (on/
o ).
16. TELETEXT – Teletext mode - To enter Teletext
17. MENU – To display OSD menu.
18. FAV – To display favourites menu.
19. EXIT – To exit all menus.
20. (▲/▼/◄/►/ OK) – Allows you to navigate the on-screen menus
and adjust the system settings to your preference. Press▲to change
picture mode during watching TV. Press▼to change sound mode
during watching TV.
21.
– To play in fast rewind mode.
22.
– To play in fast forward mode.
23.
– To play/pause
24. Rec
1
– PVR Record
25.
– To restart the current chapter
26.
– To advance forward to the next chapter
27.
– To stop the playback
28. Rec List
1
– Opens the list of recordings.
29. COLOUR BUTTONS – Additional teletext and OSD functions
1
- available only with PVR function
