LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK

136

D802 093G 64S522SEM 9JR9300000061 LL4148 1

D803 093G 6433S 9JR9300000062 DIODE BAV99 SEMTECH 1

D804 093G 64 42 PP 9JR9300000060 BAV70 SOT-23 1

D805 093G 64 42 PP 9JR9300000060 BAV70 SOT-23 1

D901 093G110090052T 9JR9300000064 DIODE UG1007 1A 1000V DO-41 1

D902 093G 60903 9JR9300000065 Diode MBRF10150CT TSC 1

D903 093G 6038T52T 9JR9300000066 FR103 1

D904 093G 64S522SEM 9JR9300000061 LL4148 1

D905 093G 60507 9JR9300000068 SRF1060 1

D906 093G100490052T 9JR9300000069 DIODE SR104 40V 1A DO-41 1

F901 084G 41 3 9JR8400000005 3.15AH/250V 1

F902 084G 56 3W 9JR8400000006 FUSE 1

FB901 071G 55906 9JR7100000023 FERRITE CORE 510R C8B R6H 6x9.2(A) 1

H4 P09T0001 1 9JR0900000002 GND TERMINAL 1

H5 P09T0001 1 9JR0900000002 GND TERMINAL 1

HD902 Q90T6064 1 9JR9000000008 HEAT SINK 1

HD905 P90T0012 1 9JR9000000003 HEATSINK(10*18*20) 1

HQ903 Q90T6064 1 9JR9000000008 HEAT SINK 1

IC801 056G 608 12 9JR5600000055 IC ta9687GN-A-0-TR SOP-16 1

IC901 056G 379128 9JR5600000056 IC LD7576 GS SOP-8 1

IC902 056G 139 7 1 9JR5600000057 IC EL817MA M-TYPE 1

IC903 056G 158 10 T 9JR5600000058 IC AS431AZTR-E1 TO-92 1

J908 061G1206000 T 9JR6100000317 RST CHIP MAX 0R05 1/4W 1

J909 095G 90 23 9JR9500000047 JUMPER WIRE 1

L801 073G 174 35 HA 9JR7300000035 IND FILTER 200mH+-25% DADON 1

L802 073G 174 35 HA 9JR7300000035 IND FILTER 200mH+-25% DADON 1

L902 073T 174900 H 9JR7300000036 LINE FILTER 9mH 1A 1

L903 073G 253 91 H 9JR7300000037 CHOKE COIL 1

L904 073G 253 91 H 9JR7300000037 CHOKE COIL 1

NR901 061G 58911 W 9JR6100000293 NTC 4A/7R 20% SCK13074MMY502 1

Q801 057G 763904 9JR5700000038 TRA FET 2N7002 SOT-23 PHILIPS 1

Q805 057T 763 91 9JR5700000039 FET AO4620 7.2A/30V -5.3A/-30V SOIC-8 1

Q806 057T 763 91 9JR5700000039 FET AO4620 7.2A/30V -5.3A/-30V SOIC-8 1

Q903 057G 600 35 9JR5700000040 STP8NK80ZFP 1

R802 061G0805512 T 9JR6100000314 RST CHIP 5K1 1/8W 5% 1

R803 061G0805512 T 9JR6100000314 RST CHIP 5K1 1/8W 5% 1

R804 061G0805821 T 9JR6100000316 RST CHIP 820R 1/8W 5% 1

R805 061G0805220 T 9JR6100000307 RST CHIP 22R 1/8W 5% 1

R806 061G0805103 T 9JR6100000302 RST CHIP 10K 1/8W 5% 1

R807 061G0805103 T 9JR6100000302 RST CHIP 10K 1/8W 5% 1

R808 061G0805473 T 9JR6100000312 RST CHIP 47K 1/8W 5% 1

R809 061G0805104 T 9JR6100000303 RST CHIP 100K 1/8W 5% 1

R810 061G0805104 T 9JR6100000303 RST CHIP 100K 1/8W 5% 1

R811 061G212Y62552T SY 9JR6100000325 RST MGFR 6.2MOHM +-5% 1/2W FUTABA 1

R812 061G0603513 T 9JR6100000298 RST CHIP 51K 1/10W 5% 1

R813 061G0805105 T 9JR6100000304 RST CHIP 1M 1/8W 5% 1

R814 061G0805821 T 9JR6100000316 RST CHIP 820R 1/8W 5% 1

R815 061G0805104 T 9JR6100000303 RST CHIP 100K 1/8W 5% 1

R817 061G0603000 T 9JR6100000296 RST CHIP MAX 0R05 1/10W 1

R818 061G0603512 T 9JR6100000012 RST CHIP 5K1 1/10W 5% 1

R820 061G 60210552T 9JR6100000295 1MOHM 5% 1/6W 1

R821 061G0805511 T 9JR6100000313 RST CHIP 510R 1/8W 5% 1

R822 061G0805682 T 9JR6100000315 RST CHIP 6K8 1/8W 5% 1

R823 061G0603105 T 9JR6100000297 RST CHIP 1M 1/10W 5% 1

R824 061G0805105 T 9JR6100000304 RST CHIP 1M 1/8W 5% 1

R825 061G0805105 T 9JR6100000304 RST CHIP 1M 1/8W 5% 1

R826 061G0805103 T 9JR6100000302 RST CHIP 10K 1/8W 5% 1

R827 061G0603103 T 9JR6100000287 RST CHIP 10K 1/10W 5% 1

R828 061G0603103 T 9JR6100000287 RST CHIP 10K 1/10W 5% 1

R829 061G0805103 T 9JR6100000302 RST CHIP 10K 1/8W 5% 1

R830 061G0805000 T 9JR6100000013 RST CHIP MAX 0R05 1/8W 1

R832 061G0805000 T 9JR6100000013 RST CHIP MAX 0R05 1/8W 1
