LC-19S7E-BK LC-26S7E-BK LC-32S7E-BK

146

C7118 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7120 065T060333312K Y 9JR6500000053 CAP CHIP 0603 33N 16V X7R +/-10% 1

C7121 065T060322412K Y 9JR6500000137 CAP CHIP 0603 0.22UF K 16V X7R 1

C7122 065T060322131J Y 9JR6500000210 CAP CHIP 0603 220PF J 50V NPO 1

C7123 065T060322232K Y 9JR6500000136 CAP CHIP 0603 2200PF K 50V X7R 1

C7124 065G080533132K Y 9JR6500000206 CAP CHIP 0805 330PF K 50V X7R 1

C7125 065T120610612K 3 9JR6500000098 CHIP 10uF 16V X7R 10% 1

C7126 067T215Y2212CT 9JR6700000113 EC 220uF 10V GL 6.3x11mm 1

C7127 067T215Y2212CT 9JR6700000113 EC 220uF 10V GL 6.3x11mm 1

C7129 067T 3152214KT 9JR6700000100 EC 220UF 25V ED 8*12mm 1

C7131 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7132 067T 3051007ET 9JR6700000006 EC 10uF 50V RGA 5x11 mm 1

C7133 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7134 067T 3051012ET 9JR6700000097 EC 100uF 10V RGA 5x11mm 1

C7156 067T 3051007ET 9JR6700000006 EC 10uF 50V RGA 5x11 mm 1

C7158 065T120610612K 3 9JR6500000098 CHIP 10uF 16V X7R 10% 1

C7159 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7160 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7161 067T 3051007ET 9JR6700000006 EC 10uF 50V RGA 5x11 mm 1

C7162 067T 3051012ET 9JR6700000097 EC 100uF 10V RGA 5x11mm 1

C7163 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7164 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7204 065T060310437Z Y 9JR6500000038 CAP CHIP 0603 0.1UF Z 50V Y5V 1

C7206 065T060310437Z Y 9JR6500000038 CAP CHIP 0603 0.1UF Z 50V Y5V 1

C7207 067T 2154714CT 9JR6700000110 EC 470uF 25V GF 10x12mm 1

C7209 065T060310437Z Y 9JR6500000038 CAP CHIP 0603 0.1UF Z 50V Y5V 1

C7210 067T 305471 7C 9JR6700000065 EC 470uF 50V KM 10x20mm 1

C7212 065T060310437Z Y 9JR6500000038 CAP CHIP 0603 0.1UF Z 50V Y5V 1

C7213 067T 3052214CT 9JR6700000061 EC 220UF/25V KM 8*11mm 1

C7301 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7302 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

C7304 065T040233031J Y 9JR6500000021 CAP CHIP 0402 33P 50V NPO +/-5% 1

C7306 065T040210412K Y 9JR6500000014 CAP CHIP 0402 100N 16V X7R +/-10% 1

CN1201 088G 78 13942 YG

9JR8800000038

RCA JACK 1*5 G/B/R/W/R RCA-512DF 1

CN1204 088T 302A12 YG

9JR8800000039

PHONE JACK 3.5mm 7P BLACK 1

CN1205 088G 7813A38C

9JR8800000040

RCA JACK 1*3 Y/W/R V/A 1

CN1206 088G 78 13934 YG

9JR8800000041

RCA JACK 1*3 Y/W/R RCA-314E-011 1

CN1401 088T 35315FTNB

9JR8800000042

D-SUB CONN V 15P F (WITH SCREW UNLOCKED) 1

CN1501 088G 340 19 VT

9JR8800000043

HDMI HEADER 19P V/T 1

CN1601 088G 34019E VD

9JR8800000041

HDMI HEADER 19P HDM24A-19BM4YN10 1

CN1703 088T 302A17 YG

9JR8800000042

PHONE JACK 3.5mm 3P V/T GREEN 1

CN1801 088G 352 2 YG

9JR8800000043

USB CONNECTOR USB4-01 1

CN1901 088T 35521U YG 9JR8800000037 SCART CONN. 21P V/T RC-2119 1

CN1902 088T 35521U YG 9JR8800000037 SCART CONN. 21P V/T RC-2119 1

CN6101 033T3802 4B Y 9JR3300000027 CONNECTOR 1

CN7201 033T380212B Y

9JR3300000044

CONNECTOR 1

CN7301 033T3802 4B Y

9JR3300000045

CONNECTOR 1

CN7303 033T3802 3E FP 9JR3300000006 WAFER 2.0MM 3P 63043 1

CN7306 033T3802 7B Y 9JR3300000040 CONNECTOR 7PIN 1

CN7503 033T8033 30 FP

9JR3300000045

WAFER 1

D1201 093G 39S925 T

9JR3300000045

DIODE AOZ8212CI-05L SOT-23 1

D1202 093G 39S925 T 9JR9300000077 DIODE AOZ8212CI-05L SOT-23 1

D1203 093G 64S522SEM 9JR9300000061 LL4148 1
