10
*1 See page 11 for external equipment connection.
*2 See page 17 for button operations.
*3 See page 8 for connecting the AC cord.
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The examples used throughout this manual are based on the LC-32SB23U model.
Part Names
TV (Front)
OPC indicator
(See page 18.)
POWER indicator
(See page 12.)
OPC sensor*
(See page 18.)
Remote control sensor
SLEEP indicator
(See page 13.)
TV (Top/Rear)
POWER button
INPUT button
MENU button
Channel buttons
(CHV/U)
Volume buttons
(VOLl/k)
*2
*3
*1
DIGITAL AUDIO OUTPUT terminal
INPUT 4 terminal (HDMI)
INPUT 5 terminals (HDMI)
INPUT 6 terminals (PC-IN)
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT terminals
SERVICE terminal
INPUT 3 terminals
AC INPUT terminal
*OPC: Optical Picture Control
LC-32SB2322021UE01.indd10LC-32SB2322021UE01.indd10 2008/07/0216:06:202008/07/0216:06:20
