Sharp LC-32SB25E Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
124
T904 080TL42T916 L XFMR 950uH PT-009601-3 9JR8000000003
T905 080TL42T923 L XFMR 2.5mH PT-009983 9JR8000000005
TH901 061T 58905 WT NTC 0R75 15% SCK100R75MSY001 BY THINKING 9JR6100000184
ZD910 093T 3990252T DIODE BZX79-C15 DO-35 9JR9300000039
ZD911 093T 3919352T TVS P6KE160A DO-15 9JR9300000038
ZD912 093G 3990752T DIO REG BZX79-C5V1 A (PHSE) A 9JR9300000034
ZD913 093G 3992152T DIODE BZX79-C9V1 DO-35 9JR9300000035
ZD914 093T 39S917 T DIODE BZX84-C20 SOT-23 9JR9300000017
ZD915 093T 39S917 T DIODE BZX84-C20 SOT-23 9JR9300000017
ZD916 093T 39S917 T DIODE BZX84-C20 SOT-23 9JR9300000017
IR PCB
1056 IRPF8PB7 IR PCB ASSY
C001 065T0603105A7Z Y CAP CHIP 0603 1U 10V Y5V -20%+80% 9JR6500000046
C002 065T060310337Z Y CAP CHIP 0603 10N 50V Y5V -20%+80% 9JR6500000033
C004 065T060310437Z Y CAP CHIP 0603 0.1UF Z 50V Y5V 9JR6500000038
CN001 033T8032 5R H X CON H 5P M 1.25 S1315-05RVA-1C 9JR3300000030
LED001 081T 14908 KB LED SM KPB-3025SURKCGKC 9JR8100000001
Q001 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
Q002 057T 477900 T TRA BC847C 100mA/50V SOT-23 9JR5700000010
R001 061T0603511 Y RST CHIPR 510 OHM +-5% 1/10W YAGEO 9JR6100000249
R002 061T0603471 Y RST CHIPR 470 OHM +-5% 1/10W YAGEO 9JR6100000111
R004 061T0603222 Y RST CHIPR 2.2KOHM +-5% 1/10W YAGEO 9JR6100000091
R006 061T0603222 Y RST CHIPR 2.2KOHM +-5% 1/10W YAGEO 9JR6100000091
R007 061T0603272 Y RST CHIPR 2.7KOHM +-5% 1/10W YAGEO 9JR6100000098
R008 061T0603101 Y RST CHIPR 100 OHM +-5% 1/10W YAGEO 9JR6100000066
U001 056T 627902 IC TSOP34438ST1 9JR5600000021
Key PCB
1057 KEPF8PB2 KEY BOARD
C023 065T060310437Z Y CAP CHIP 0603 0.1UF Z 50V Y5V 9JR6500000038
C024 065T060310437Z Y CAP CHIP 0603 0.1UF Z 50V Y5V 9JR6500000038
CN016 033T3802 4 H X WAFER 4P RIGHT ANGLE PITCH 2.0 9JR3300000019
R016 061T0603113 Y RST CHIPR 11KOHM +-5% 1/10W YAGEO 9JR6100000218
R017 061T0603432 Y RST CHIPR 4.3KOHM +-5% 1/10W YAGEO 9JR6100000105
R018 061T0603182 Y RST CHIPR 1.8KOHM +-5% 1/10W YAGEO 9JR6100000082
R019 061T0603471 Y RST CHIPR 470 OHM +-5% 1/10W YAGEO 9JR6100000111
R020 061T0603113 Y RST CHIPR 11KOHM +-5% 1/10W YAGEO 9JR6100000218
R021 061T0603432 Y RST CHIPR 4.3KOHM +-5% 1/10W YAGEO 9JR6100000105
R022 061T0603182 Y RST CHIPR 1.8KOHM +-5% 1/10W YAGEO 9JR6100000082
SW016 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW017 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW018 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW019 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW020 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW021 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
SW022 077T 600 1GCJ TACT SWITCH TSPB-2 -NP 9JR7700000001
