Sharp LC-32SB25E Service Manual

2008-03-14
LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
125
Model: LC-32SB25E(CMO)
Item Code number Description Sharp C/N
Mechanical Parts
30 705TP834025 BEZEL ASSY 9JR7050000014
35 705TP833007 KEY PAD ASSY 9JR7050000011
40 705TP834026 REAR COVER ASSY 9JR7050000015
50 705TP837008 BASE ASSY 9JR7050000018
60 705TP837009 BASE STAND ASSY 9JR7050000019
1185 078T 495902 1M Speaker 8ohm/6W 120mmX30mm 9JR7800000002
1186 078T 495902 1M Speaker 8ohm/6W 120mmX30mm 9JR7800000002
Accessory
1172 089T404A18NHT2 POWER CORD 1.8M 4L4L-040-00K 9JR8900000003
1176 098TRABD5NESHC REMOTE CONTROL RL57S 9JR9800000002
705TZ841028 DFU ASSY 9JR7050000023
705TZ841031 DFU ASSY 9JR7050000024
Packing
451 705TZ8CS008 Cushion_Assy 9JR7050000027
450 P44TJ017843 1A CARTON 9JR4400000013
miscellanea
98 0Q1T 930 8 47 CR3 SCREW 9JR0100000007
99 0M1T 940 16 47 CR3 SCREW M4X6 9JR0100000002
100 0Q1T 940 16 47 CR3 SCREW 9JR0100000020
101 0M1T 940 8120 SCREW 9JR0100000017
102 0Q1T1040 8120 SCREW 9JR0100000010
104 0M1T1730 8106 CR3 SCREW 9JR0100000019
105 0M1T1140 6120 SCREW 4*6MM 9JR0100000003
106 0M1T 330 6 47 CR3 SCREW 9JR0100000001
108 052T 1211551 AL FOIL (30x100mm) (CMO) 9JR5200000003
111 0Q1T1830 12 47 CR3 SCREW_THW K30x12 PT W=8.5 9JR0100000022
112 0Q1T 330 5120 SCREW 9JR0100000006
126 P40TJV0084336A RATING LABEL 9JR4000000027
127 P40TA00081328A FAMILY SHEET- SERVICE 9JR4000000004
130 P40TJ00084384A CARTON LABEL 9JR4000000026
137 P40TN00084342B LABEL_SIDE_IO 9JR4000000021
143 P45T 48005 1A P.E. BAG(100 X 70) 9JR4500000003
144 P41TN025843 1C QSG-1 (Western & North Europe) 9JR4100000008
145 P41TN026843 1B QSG-2 (Eastern Europe & Russia) 9JR4100000009
455 P45T 46024 PE BAG(950X735x0.72mm) 9JR4500000006
8390 095T8014 4F927 HARNESS 4P-4P 520mm 75267 9JR9500000009
8391 095T8014 5F914 HARNESS 5P-5P 380mm 75266 9JR9500000012
8600 095T8013 2FA16 Harness 2P-FAST*2 440mm 76823 9JR9500000024
8601 095T8013 3FA06 Harness 3P-FAST*2 820mm 76824 9JR9500000025
8750 095T8018 30962 FP HARNESS 30P-20*2P 150mm 75199 9JR9500000020
8902 095T801412FA15 Harness 12P-12P 115mm 76810 9JR9500000031
8903 095T801414F923 HARNESS 14P-13P 160mm 75264 9JR9500000018
LCD panel
1050 750TVMM5B1113N PANEL V315B1-L01 C2 NH CMO 9JR7500000003
PCB assy
1053 CBPF82MBPN Main Pcb Assy SHARP 32"CMO 9JR9900000008
1054 ADTV82420PA3 POWER PCB ASSY 9JR9900000005
1056 IRPF8PB7 IR PCB ASSY 9JR9900000009
1057 KEPF8PB2 KEY BOARD 9JR9900000010
Main PCB
1053 CBPF82MBPN Main Pcb Assy SHARP 32"CMO
1261 TUPF8PD3 TUNER+EEPROM ASSY 9JR9900000015
1262 705TP856109 NOR FLASH ASSY (U390) 9JR7050000033
1302 705TP856108 Serial IIC EEPROM ASSY (CMO-Panasonic) 9JR7050000032
C101 067T 3051013LT EC 100uF 16V RGA 6.3x11mm 9JR6700000059
C102 065T060333312K Y CAP CHIP 0603 33N 16V X7R +/-10% 9JR6500000053
C104 065T060333312K Y CAP CHIP 0603 33N 16V X7R +/-10% 9JR6500000053
C105 065T060310412K Y CAP CHIP 0603 0.1UF K 16V X7R 9JR6500000036
C106 065T060310412K Y CAP CHIP 0603 0.1UF K 16V X7R 9JR6500000036
C107 067T 215471 3C EC 470uF 16V GF 8x16mm 9JR6700000004
C108 065T120610612K 3 CHIP 10uF 16V X7R 10% 9JR6500000098
C109 065T060310412K Y CAP CHIP 0603 0.1UF K 16V X7R 9JR6500000036
