Sharp LC-37D90U Supplemental Service Manual

LC-37D90U
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] LCD MODULE Assembly
1 R1LK370D3LZ1AB EZ N J LCD Module Ass'y
2 QPWBM0197TPZZ AH N J CS-FPC1,x2
3 CPWBX3348TPZC BV N J LCD CONTROL Unit
4 PSLDMA992WJFW AL N J Cover (LCD Control Unit (Top))
5 PSLDMA804WJM1 AM N J Cover (LCD Control Unit (Bottom))
6 LX-BZ2118TPZZ AA N J Screw (for Vessel), x10
7 XBPS730P06WS0 AA J Screw (for INV, LCD CONTROL), x13
8 CCHSMA310WJ01 BP N J Chassis Ass'y
9 KLMP-A127WJZZ BA N J Lamp Unit, x11
10 LHLDZA682WJKZ AX N J Lamp Holder, x2
11 PCOVUA090WJZZ BA N J Diffusion Panel
12 PSHEPA423WJZZ AU N J Reflection Sheet
13 PSHEPA424WJZZ BM N J Prism Sheet
14 PSHEPA425WJZZ BT N J Optical Sheet
15 PSLDMA953WJFW AN N J Inverter Cover
16 RUNTKA244WJZZ BM N J INVERTER Unit A
17 RUNTKA245WJZZ BG N J INVERTER Unit B
18 PSPAZB030WJKZ AB N J Inverter Spacer, x9
19 RCORFA061WJZZ AG N J Core, x2
20 PTPEZA018WJZZ AD N J PET Tape, x2
21 PZETE3914TPZZ AD N J Tape, x2
22 PZETE3915TPZZ AB N J Tape
23 PSHEP2529TPZZ AB N J Conductive Tape, x4
24 PSHEP2583TPZZ AC N J Conductive Tape
