NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM)
DUNTKD641FM10 - - R/C, LED Unit
DUNTKD643FM11 - - IF Unit
DUNTKD716FM06 - - KEY Unit
DKEYDD743FM21 - - MAIN Unit
DUNTKD744WE01 - - SPEAKER TERMINAL-L Unit
DUNTKD745WE01 - - SPEAKER TERMINAL-R Unit
RDENCA169WJQZ - - POWER Unit
[2] LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPEN-
DENTLY.)
R1LK370D3LZ1AB EZ X 37" WIDE LCD Panel Module Unit
[3] DUNTKD641FM10 (R/C, LED Unit)
C101 VCERMZ1CN107MY AD J Capacitor, 100 16V Capacitor(AL)
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C103 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
D101 RH-EXA092WJZZY AB J Diode, UDZSTE-1712B
D102 RH-PXA087WJZZY AG J Diode, CL-196HB1-D-T
D103 RH-PX0421CEZZY AD J Diode, CL-165HR/YG-D-T
IC101 VHiTPS850++-1Y AG J IC, TPS850
P101 QPLGNA331WJZZY AD J Plug, 11pin (RA)
Q101 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q102 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R103 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R104 VRS-CY1JF273JY AA J Resistor, 27k 1/16W Metal Oxide
R106 VRS-CY1JF221JY AA J Resistor, 220 1/16W Metal Oxide
R107 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R109 VRS-CY1JF161JY AA J Resistor, 160 1/16W Metal Oxide
R115 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDM4646CEFW AD J Shield
[4] DUNTKD643FM11 (IF Unit)
C501 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C502 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C503 RC-KZA510WJPZY AB J Capacitor
C504 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C505 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C506 RC-KZA510WJPZY AB J Capacitor
C507 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C508 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C509 RC-KZA510WJPZY AB J Capacitor
C512 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C515 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C518 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C519 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C520 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C521 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C522 VCKYTV1CB105KY AC J Capacitor, 1 16V Ceramic
C523 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C524 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C525 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C526 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C527 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C528 VCERML1CN226MY AC J Capacitor, 22 16V Capacitor(AL)
C529 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C530 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C532 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C533 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C534 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C535 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C536 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
C537 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
C538 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
C540 RC-KZA510WJPZY AB J Capacitor
C541 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
C542 VCKYCY1EF104ZY AA J
Capacitor, 0.1 25V Ceramic
C544 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C545 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C546 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C547 VCERMZ1CN107MY AD J Capacitor, 100 16V Capacitor(AL)
C551 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C552 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C553 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C554 VCAAPF1CJ396MY AF J Capacitor, 39 16V Electrolytic
C555 RC-KZA154WJZZY AB J Capacitor
C556 RC-KZA154WJZZY AB J Capacitor
C557 RC-KZA104WJZZY AA J Capacitor, 1 25V Ceramic
C559 RC-KZA109WJZZY AC J Capacitor
C560 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C564 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
C569 VCKYCH1CB104KY AB J Capacitor, 0.1 16V Ceramic
