LC-37D90U
31
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[9] CABINET AND MECHANICAL PARTS
1 CCABAB315WJ01 X Front Cabinet Ass'y
1-1 Not Available - - Front Cabinet
1-2 GCOVAB501WJSA X LED Cover
1-3 Not Available - - Badge, SHARP
1-4 HDECCA010WJSA X Decoration Plate
1-5 PSPAHA416WJZZ AC X Spacer, x2
1-6 PSPAHA801WJZZ X Spacer, x2
2 CCABBA764WJ01 X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 HiNDPB700WJSA X Indicator
2-3 LHLDWA131WJKZ AE X Wire Holder
2-4 LHLDZA644WJZZ AD X Wire Holder, x2
3 CCOVAB497WJ01 X Top Cover Ass'y
3-1 Not Available - - Top Cover
3-2 JBTN-A429WJKA X Power Button
3-3 JBTN-A535WJKA X Operation Button
3-4 MSPRCA049WJFW AC X Power Button Spring
4 CDAi-A195WJKA X Stand Base Ass'y
4-1 GDAi-A195WJKA X Stand Base
4-2 LANGKA443WJSA X Base Angle
4-3 PSPAZA476WJZZ AC X LEG Cushion-B, x2
4-4 PSPAZA477WJZZ AD X LEG Cushion-C, x4
4-5 PSPAZA617WJZZ AD X LEG Cushion-A, x2
5 CHNG-A105WJSA X Stand Hinge Ass'y
5-1 GDAi-A196WJSA X Stand Support
5-2 GDAi-A200WJF7 X Swivel Base
5-3 MHNG-A105WJSA X Stand Hinge
6 XCSSN50P25000 AB X Screw (for Stand), x5
7 R1LK370D3LZ1AB EZ X 37" WIDE LCD Panel Module Unit
8 DKEYDD743FM21 - - MAIN Unit
9 DUNTKD643FM11 - - IF Unit
10 DUNTKD716FM06 - - KEY Unit
11 DUNTKD641FM10 - - R/C, LED Unit
12 DUNTKD744WE01 - -
SPEAKER TERMINAL-L Unit
13 DUNTKD745WE01 - - SPEAKER TERMINAL-R Unit
14 RDENCA169WJQZ - - POWER Unit
15 CANGKA702WJ01 X Center Angle Ass'y
15-1 Not Available - - Center Angle
15-2 PSPAHA811WJZZ X Spacer, x2
16 CANGKA722WJ01 X SUS Angle (L) Ass'y
16-1 Not Available - - SUS Angle (L)
16-2 PSHEPA454WJU0 X Spacer
17 CANGTA317WJ01 X Fan Angle (L) Ass'y
17-1 Not Available - - Fan Angle (L)
17-2 LHLDWA123WJKZ X Wire Holder
17-3 PSPAGA329WJ00 X Spacer, x4
17-4 XBPS730P08WS0 AH X Screw, x2
18 CANGTA330WJ01 X Fan Angle (C) Ass'y
18-1 Not Available - - Fan Angle (C)
18-2 LHLDWA092WJZZ AB X Wire Holder, x4
18-3 PSPAGA329WJ00 X Spacer, x4
18-4 XBPS730P08WS0 AH X Screw, x2
19 GCOVAA678WJKA AE X SD Card Cover
20 GCOVAB166WJKB AP X Hinge Cover
21 GCOVAB582WJKA AN X Stand Cover
22 HiNDPB695WJSA X Jack Indicator
23 HiNDPB670WJSA X MODEL Label
24 LANGKA644WJFW X Jack Angle Long
25 LANGKA701WJFW X Fixing Angle Top, x2
26 LANGKA703WJFW X SP Fixing Angle, x2
27 LANGKA720WJN1 X Stand Fixing Angle
28 LANGKA721WJN1 X SUS Angle (R)
29 LANGKA749WJFW X RS232C Angle
30 LBSHZA005WJZZ X Washer, x2
31 LCHSMA286WJFW X Chassis
32 LHLDW1025TAZZ AB X Wire Holder, x2
33 LHLDW1141CEZZ AE X Wire Holder
34
LHLDWA004WJZZ AD X Wire Holder, x4
35 LHLDWA043WJKZ AB X Wire Holder, x2
36 LHLDWA048WJKZ AB X Wire Holder
37 LHLDWA092WJZZ AB X Wire Holder
38 LHLDWA096WJKZ AD X Wire Holder
39 LHLDWA145WJKZ AC X Wire Holder, x2
40 NFANR0126CEZZ AT X Fan, x2
41 NSFTZ0134CEFW AD X Shaft, x4
42 PRDARA192WJFW AE X Heat Sink (for AV Switch)
43 PRDARA204WJFW X Heat Sink (for AMP-Bottom)
44 PRDARA312WJFW X Heat Sink (for AMP-Top)
45 PRDARA338WJFW X Heat Sink (for MAIN Unit)
46 PSLDMA910WJFW X MAIN Shield
47 PSPAZA635WJKZ AC X Spacer (IC501/2701 Cool Sheet), x2
48 PSPAZA700WJKZ AD X Spacer (IC2701 Cool Sheet)
49 PSPAZA917WJKZ AH X Spacer (IC8101/3301 Cool Sheet), x2
50 PSPAZB192WJKZ X Spacer (IC8601 Cool Sheet)
51 QCNW-E386WJQZ AF X Connecting Cord (KM:MAIN-KEY)
