Adjust RB to the target xy values.
MG5RXXXX
MG5BXXXX
* XXXX indicates adjustment values between 0000 - 1023 (4 digit decimal number with zero fill).
* G is fixed.
* Default adjustment value of RGB is the parameter value of LEV5 command multiplied by 4.
Adjustment values are set.
OK
Adjustment gradation setting (Standard value 4 = 144 gradation)
LEV40164
Adjustment value is set.
OK
Correct G value.
MG4GXXXX
Adjustment value is set.
OK
Adjust RB to the target xy values.
MG4RXXXX
MG4BXXXX
* XXXX indicates adjustment values between 0000 - 1023 (4 digit decimal number with zero fill).
* G is fixed.
* Default adjustment value of RGB is the parameter value of LEV4 command multiplied by 4.
Adjustment values are set.
OK
Adjustment gradation setting (Standard value 3 = 116 gradation)
LEV30132
Adjustment value is set.
OK
Correct G value.
MG3GXXXX
Adjustment value is set.
OK
Adjust RB to the target xy values.
MG3RXXXX
MG3BXXXX
* XXXX indicates adjustment values between 0000 - 1023 (4 digit decimal number with zero fill).
* G is fixed.
* Default adjustment value of RGB is the parameter value of LEV3 command multiplied by 4.
Adjustment values are set.
OK
Adjustment gradation setting (Standard value 2 = 66 gradation)
LEV20088
Adjustment value is set.
OK
Correct G value
MG2GXXXX
Adjustment value is set.
OK
When G is changed at adjustment gradation setting (standard value 6 = 236 gradation), calculate
the ratio of the change and set the following value to XXXX: (the value set with LEV2) x 4 x (the ratio).
When G is changed at adjustment gradation setting (standard value 6 = 236 gradation), calculate
the ratio of the change and set the following value to XXXX: (the value set with LEV3) x 4 x (the ratio).
Start of measurement
When G is changed at adjustment gradation setting (standard value 6 = 236 gradation), calculate
the ratio of the change and set the following value to XXXX: (the value set with LEV4) x 4 x (the ratio).
Start of measurement
Repeat until values are
properly adjusted.
Repeat until values are
properly adjusted.
Repeat until values are
properly adjusted.
Start of measurement
Reflecting adjustment values to
images
Pattern display
Reflecting adjustment values to
images
Reflecting adjustment values to
images
Pattern display
Pattern display
