LC-37D90U
5 – 30
60 MODE2 I Input signal state detection.
61 PMUTE O Video mute.
62 DDCRST O IC1 reset.
63 TVPOW2 O LCD TOP PWB 1.2V/2.5V power control.
64 STB O Backlight control.
65 PANEL_POW O Panel power control signal.
66 VSH_OUT O Panel 3.3V control.
67 MP_CLK I 3-wire serial clock.
68 MP_DI I 3-wire serial input.
69 MP_DO O 3-wire serial output.
70 CPLD_OE O CPLD output permit control.
71 MP_CS O 3-wire serial chip select.
72 DAC_CS O 3-wire serial chip select (only for MB88146).
73 PANEL_SW O Panel power control signal.
74 AVSS --- GND.
75 QSTEMP I Monitor internal temperature check.
76 KEY1 I On-set key input 1.
77 KEY2 I On-set key input 2.
78 KEY3 I On-set key input 3.
79 AREA1 I Destination setting 1.
80 AREA2 I Destination setting 2.
Pin No. Pin Name I/O Pin Function
