LC-37D90U
5 – 60
60 GND --- Ground.
61 PWB_VER1 I PWB ID.
62 CLK33MB I Clock (33MHz).
63 VCC --- Power Supply.
64 N_SRESET I System Reset.
65 GND --- Ground.
66 PWB_VER0 I PWB ID.
67 HDMI_HPG1 I
68 HDMI_HPG2 I
69 HDMI_HPG3 I
70 HDMI_RST O
71 HDMI_SW_EMP O
72 HDMI_INT I
73 HDMI_SW_OE O
74 HDMI_SEL1 O
75 HDMI_SEL2 O
76 HDMI_SEL3 O
77 HDMI_PLG_EN O
78 HDMI_WP O
79 GND --- Ground.
80 VCC --- Power Supply.
81 HP_WATCH I EX Model Control Line.
82 HP_IPDET I EX Model Control Line.
83 CPLD_INT1 O CPLD Interrupt (Reservation).
84 TUNER_INT O Tuner Interrupt Notice.
85 CPLD_INT0 O CPLD Interrupt.
86 N_CPU_RST O CPU Reset.
87 EA5 I SBADD5.
88 EA4 I SBADD4.
89 EA3 I SBADD3.
90 EA2 I SBADD2.
91 EA1 I SBADD1.
92 HP_RST O EX Model Control Line.
93 GND --- Ground.
94 VCC --- Power Supply.
95 HP_IPEN O EX Model Control Line.
96 TP ---
97 TP ---
98 TP ---
99 N_SBCE5 I
100 N_SBCE0 I
Pin No. Pin Name I/O Pin Function
