Sharp LC-40CFE6131K User Manual

15
15
CONNECTIONS
A
C
D
E
F
G
H
I
J
K
L
M
N
B
LAN* Network connection
HDMI 1 HDMI input
HDMI 2 HDMI input (ARC)
VGA PC VGA-PC input
SCART SCART input
RF in RF / TV aerial input
Digital audio Digital optical audio output
HDMI 3 HDMI input
USB x 2 USB port
VGA PC audio in 3.5mm PC audio input
AV in Audio/video input
CI card in Common interface module
YPbPr HD input (Ypbpr)
Earphones Earphone input
A
I
L
B
J
M
N
C
D
E
F
G
H
K
The LAN/Ethernet port is used for Freeview HD services and smart functions.
VGA/PC IN
Digital Audio
Output
EARPHONE
USB
CI CARD IN
VGA/PC(Audio in)
AV IN Y Pb Pr
Connections
Input/Outputs for the LC-32CHE6131K, LC-40CFE6131K
and LC-43CFE6131K.
User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:15User Guide - SHA-MAN-0005 - SmartTV - LC 32,40,43,49,50 inch models.indd Sec1:15 13/08/2015 10:06:2513/08/2015 10:06:25

Sharp LC-40CFE6131K Specifications

General

Brand	Sharp
Model	LC-40CFE6131K
Category	TV
Language	English
