LC-40E67U/LC-40E77U
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[6] CABINET AND MECHANICAL PARTS
1 CCABAC293WJ02 BS N X Front Cabinet Ass'y (LC-40E67U)
1 CCABAC293WJ01 BS N X Front Cabinet Ass'y (LC-40E77U)
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Bottom Decoration-A Ass'y (LC-40E67U)
1-2 Not Available - N - Bottom Decoration-A Ass'y (LC-40E77U)
1-2-1 Not Available - N - Bottom Decoration-A (LC-40E67U)
1-2-1 Not Available - N - Bottom Decoration-A (LC-40E77U)
1-2-2 HBDGBA061WJSA AH J SHARP Badge
1-3 Not Available - - LED Cover
1-4 TLABZC154WJZZ AH X E67 POP Label (LC-40E67U)
1-4 TLABZC190WJZZ AG X E77 POP Label (LC-40E77U)
1-5 XEBS740P10000 AB J Screw, x7
2 CCABBB519WJ02 BK N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPD205WJSA AF X Terminal Label
3 CCOVAD295WJ04 AL N X Side AV Cover Ass'y
3-1 Not Available - N - Side AV Cover
3-2 Not Available - N - Terminal Label
4 CCOVAC952WJ01 AK X KEY Button Cover Ass'y
4-1 GCOVAC952WJKA AK N X KEY Button Cover
4-2 Not Available - N - Control Button Label
5 CSLDMB612WJ01 AV X Control Shield Ass'y (LC-40E77U only)
5-1 Not Available - N - Control Shield (LC-40E77U only)
5-2 PRDARA644WJFW AP X Control Raadiator (LC-40E77U only)
5-3 XBPS730P06WS0 AA J Screw(for Radiator), x6 (LC-40E77U only)
6 GCOVAC576WJKZ AC J VESA Hole Cover, x4
7 GCOVAD282WJ3A AN X Bottom Cover
8 GCOVAD297WJ3A AD X Bus Conn Cover
9 HINDPD280WJSA AD N X Model Label (LC-40E67U)
9 HINDPD279WJSA AD N X Model Label (LC-40E77U)
10 LANGKC082WJFW AC X MAIN PWB Angle, x2
11 LANGKC195WJM1 AS N X Support Angle, x2
12 LHLDFA040WJKZ AC J Wire Holder (for POWER PWB)
13 LHLDFA045WJKA AG X
POWER PWB Holder, x2
14 LHLDWA074WJKZ AD J Wire Holder (LC-40E77U only)
15 LHLDWA143WJKZ AC J Wire Holder, x2
16 LHLDWA151WJKZ AB J Wire Holder
17 LHLDWA175WJUZ AC J Wire Holder, x6 (LC-40E67U)
17 LHLDWA175WJUZ AC J Wire Holder, x5 (LC-40E77U)
18 LHLDWA176WJUZ AC J Wire Holder (for LW)
19 NSFTZA284WJFW AC J Hwxagon Nut, x4
20 PMLT-A593WJZZ AC X Gasket:8X35X7T, x5
21 PMLT-A594WJZZ AD X Gasket:8X50X7T, x5
22 PMLT-A597WJQZ AF X Gasket(TUNER)
23 PSLDMB560WJFW AR X MAIN PWB Shield
24 PSPAZB963WJKZ AD J Conductor(JACK), x2
25 QCNCMA275WJQZ AC J Connecting Cord(MODEL SELECTOR), x2
26 QCNW-H539WJPZ AK X Connecting Cord(SP)
27 QCNW-H813WJQZ AF N X Connecting Cord(PL)(LC-40E77U only)
28 QCNW-H953WJQZ AE X Connecting Cord(KM)(LC-40E67U)
28 QCNW-H953WJQZ AE X Connecting Cord(KM)(LC-40E77U)
29 QCNW-J130WJQZ AH X Connecting Cord(LP)(LC-40E77U only)
30 QCNW-J131WJQZ AH X Connecting Cord(LB1)(LC-40E67U)
30 QCNW-J131WJQZ AH X Connecting Cord(LB1)(LC-40E77U)
31 QCNW-J134WJQZ AH X Connecting Cord(RA)
32 QCNW-J467WJQZ BC N X Connecting Cord(LW)(LC-40E67U)
32 QCNW-J449WJQZ AW N X Connecting Cord(LW)(LC-40E77U)
33 QCNW-J453WJQZ AF N X Connecting Cord(LB2)
34 QCNW-J456WJQZ AH N X Connecting Cord(LA)
35 QCNW-J459WJQZ AM X Connecting Cord(PD)
36 RSP-ZA391WJZZ AP J Speaker(L)
37 RSP-ZA392WJZZ AP J Speaker(R)
38 TLABNB037WJZZ AB X Back Serial Label
39 Not Available - N - Side Serial Label
40 TLABK0023TAZZ AA J Bar Code Label
41 XBPS830P06000 AA J HDMI Screw, x3
42 XEBS740P10000 AB J Screw(FOR CAB-A), x2
43
XEBS930P10000 AA J Screw(S-VIDEO)
44 XEBS940P16000 AB J Screw(CAB-A/B), x10
45 XHPS830P06WS0 AA J Screw, x27(LC-40E67U)
45 XHPS830P06WS0 AA J Screw, x31(LC-40E77U)
46 XHPS830P10WS0 AB J Screw(FOR CAB B)
47 XHPS830P18WS0 AB J Screw(POWER-PWB), x4
48 XIPSN20P04000 AA J Screw(SIDE HDMI), x2
