LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S

4 – 3

2. Removing of Side Terminal Angle Ass’y, Main PWB Shield, Speaker-L/R and Bottom Cover Ass’y.

1. Detach the Side Terminal Angle Ass’y .

2. Remove the 4 lock screws , 1 lock screw , 4 lock shafts and 5 lock screws and detach the Main PWB Shield .

3. Disconnect SP wire.

4. Detach the Speaker-L , Speaker-R .

5. Remove the 2 hooks and detach the Bottom Cover Ass’y .

䎶䎳

䎘

䎖

䎗

䎙

䎕

䎰䏄䏌䏑䎃䎳䰣䰎䙤䎶䏋䏌䏈䏏䏇

䎕

䎔

䎶䏌䏇䏈䎃䎷䏈䏐䏌䏑䏄䏏䎃

䎤䏑䏊䏏䏈䎃䎤䏖䏖䎊䏜

䎶䏓䏈䏄䏎䏈䏕䎐䎵

䎶䏓䏈䏄䏎䏈䏕䎐䎯

䎛

䎚

䎥䏒䏗䏗䏒䏐䎃䎦䏄䏙䏈䏕䎃䎤䏖䏖䎊䏜

䎜

䎶䎳

Hook
