Sharp LC-40LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] LCD PANEL MODULE UNIT (LC-32LE/LU/LX700)
1 DLCUCA001FM03 P 32" LCD Panel Module Unit
1-1 PRDARA787WJZZ P Back Light Chassis
1-2 LHLDWA284WJKZ AC J Bush Base
1-3 LHLDWA280WJKZ AC N J Wire Holder, x3
1-4 RUNTK4225TPZE BR N P LCD Control Unit
1-5 XHPS730P06WS0 AA J Screw, x6
1-6 QCNW-H089WJQZ AG N J Connecting Cord, x2
1-7 RCORFA061WJZZ AG J Ferrite Core, x2
1-8 QCNW-J644WJQZ N P Wire Harness
1-9 CHLDWA285WJ01 AC J Bush Cap Unit
1-10 RUNTKA598WJ01 P LED8 PWB1 Unit, x4
1-11 RUNTKA598WJ02 P LED8 PWB2 Unit, x4
1-12 QCNCWA958WJZZ AD N J Terminator, x8
1-13 RUNTKA595WJ01 AX J LED5 PWB1 Unit, x4
1-14 RUNTKA595WJ02 AX J LED5 PWB2 Unit, x4
1-15 LHLDZB497WJKZ AC N J Push Rivet, x48
1-16 PMIR-A254WJZZ N P Reflection Sheet
1-17 LHLDZB496WJKZ AC N J Support Pin, x4
1-18 PCOVUA183WJZZ N P Diffusion Plate
1-19 PSHEPA973WJZZ N P Lens Sheet
1-20 PSHEPA963WJZZ N P Optical Sheet
1-21 CHLDZB528WJ01 N P Panel Chassis Ass'y
1-22 R1LK315D3FZE0Y CS N P 32" LCD Panel HIRAKI Unit
1-23 CANGKC321WJ01 P Bezel Ass'y (Top)
1-24 CANGKC326WJ01 N P Bezel Ass'y (Bottom)
1-25 CANGKC327WJ01 N P Bezel Ass'y (L)
1-26 CANGKC328WJ01 N P Bezel Ass'y (R)
1-27 LX-EZA028WJF9 AB J Screw, x10
1-28 LX-HZA039WJF7 AB J Screw, x10
1-29 TLABN2229TPZZ AA J Bar Code Label
1-30 PSHEPB013WJZZ AT N P Micro Lens Sheet

Sharp LC-40LE700E Specifications

General

Comb filter	3D
Display diagonal	40 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Power requirements	AC220V-AC240V/50Hz-60Hz
HDMI ports quantity	4
SCART ports quantity	2
Digital audio optical out	1
Cables included	AC
Product color	Black

Weight and Dimensions

Weight (with stand)	11600 g
Depth (without stand)	93.1 mm
Width (without stand)	964 mm
Height (without stand)	612 mm
