Sharp LC-40LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
22
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] CABINET AND MECHANICAL PARTS (LC-40LE/LU/LX700)
1 CCABAC372WJ11 BK N P Front Cabinet Ass'y (LC-40LE700)
1 CCABAC372WJ14 N P Front Cabinet Ass'y (LC-40LU700)
1 CCABAC372WJ13 N P Front Cabinet Ass'y (LC-40LX700)
1-1 Not Available - N - Front Cabinet
1-2 Not Available - N - Front Decoration Ass'y (LC-40LE700)
1-2 Not Available - N - Front Decoration Ass'y (LC-40LU700)
1-2 Not Available - N - Front Decoration Ass'y (LC-40LX700)
1-2-1 HBDGBA070WJSA AF J SHARP Badge
1-2-2 Not Available - N - Front Decoration
1-2-3 Not Available - S - Center Decoration (LC-40LE700)
1-2-3 Not Available - S - Center Decoration (LC-40LU700)
1-2-3 Not Available - S - Center Decoration (LC-40LX700)
1-3 Not Available - S - LED Decoration
1-4 Not Available - S - Diffusion Sheet
1-5 Not Available - N - Front Cabinet Spacer, x2
1-6 Not Available - N - Double Tape
1-7 XEBSN40P10000 AB J Screw for Decoration, x6
2 CCABBB618WJ11 BH N P Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - S - Terminal Label
2-3 Not Available - N - Rear Cabinet Spacer, x2
3 CBTN-A844WJ11 AH S P Control Button Ass'y
3-1 Not Available - N - Control Button Label
3-2 Not Available - N - Control Button
4 CCOVAD464WJ11 AM N P Bottom Cover Ass'y
4-1 Not Available - N - Bottom Cover
4-2 Not Available - S - Reflect Sheet
5 CANGKC375WJ01 AL S P Side Terminal Angle Ass'y
5-1 Not Available - N - Side Terminal
5-2 Not Available - N - Side Terminal Angle
5-3 Not Available - N - Heat Protect Sheet
6 CANGKC424WJ01 AT N P Support Angle Ass'y, x2
6-1 Not Available - N - VESA Bracket, x2
6-2 Not Available - N -
Support Angle
6-3 XHPS730P06WS0 AA J Screw for VESA Bracket, x4
7 LANGKC480WJFW AB N P Side Lug, x2
8 LHLDQA001WJ1A AF S P ECO Switch Holder
9 LHLDWA175WJUZ AC J Wire Holder, x4
10 LHLDWA176WJUZ AC J Wire Holder, x2
11 LHLDWA289WJKZ AC N J Wire Holder, x3
12 LHLDZA587WJKZ AC J PWB Spacer, x2
13 NSFTZA243WJFN AB J Shaft for D-SUB, x4
14 PCUSGA079WJZZ AA P Screw Cushion, x4
15 PMLT-A608WJZZ AB N P Gasket:8x16x5.5
16 PSLDMB665WJFW AM N P MAIN Shield
17 QCNW-J903WJQZ AK N J Connecting Cord(PD)
18 QCNW-J917WJQZ AK N J Connecting Cord(LB)
19 QCNW-J979WJQZ AE N P Connecting Cord(KM)
20 QCNW-J805WJQZ AF P Connecting Cord(RA)
21 QCNW-G178WJQZ AG J Connecting Cord(PL)
22 QCNW-J902WJQZ AX N P Connecting Cord(LW)
23 QCNW-J901WJQZ AH N P Connecting Cord(SP)
24 QCNW-J712WJQZ AF P Connecting Cord(LP)
25 QCNW-J838WJQZ AF J Connecting Cord(IM)
26 QCNW-J996WJQZ AU N P Connecting Cord(AS)
27 QEARPA339WJFW AB P Earth Plate
28 RSP-ZA391WJZZ AP J Speaker-L
29 RSP-ZA392WJZZ AP J Speaker-R
30 TLABNC117WJZZ AA P Model Label
31 TLABK0023TAZZ AA J Bar Code Label
32 TLABZB406WJZZ AC P ECO Label (except for Russia)
33 TLABZC319WJZZ AK N P POP Label (except for Russia)
33 TLABZC320WJZZ AM P POP Label (for Russia)
34 XBBS730P04000 AA J Screw for Tuner
35 XBPS730P06000 AA J Screw for HDMI, x4
36 XBPS730P06WS0 AA J Screw for ECO Switch
37 XEBS730P08000 AA J Screw for Side Lug, x3
38
XEBS740P12000 AD J Screw for Front Cabinet/LCD, x8
39 XEBS740P16000 AA P Screw for Front/Rear Cabinet, x5
41 XHPS730P06WS0 AA J Screw for PWB/Support Angle, Rear Cabinet/LCD, x33
42 XWHS735-05120 AA P PWB Washer, x2

Sharp LC-40LE700E Specifications

General

Comb filter	3D
Display diagonal	40 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Power requirements	AC220V-AC240V/50Hz-60Hz
HDMI ports quantity	4
SCART ports quantity	2
Digital audio optical out	1
Cables included	AC
Product color	Black

Weight and Dimensions

Weight (with stand)	11600 g
Depth (without stand)	93.1 mm
Width (without stand)	964 mm
Height (without stand)	612 mm
