Sharp LC-40LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
6 – 8
No sound from external input devices (4)
Does not the sound of the audio signal input to EXT8 go out?
Is there a audio input signal in pins(5/CVBS_IN_L) and (4/
CVBS_IN_R) of EXT8(J506)?
NO Check the setting of an external input device that connects with
EXT8.
YES
Is there a audio input signal in pins (R28/CVBS_L) and (T28/
CVBS_R) of IC3302 (Digital AV decode & Main CPU) from J505?
NO Check IC3302 and its peripheral circuits.
YES
Refer to “No sound output in all modes”.
No sound from external input devices (5)
Does not the sound of the audio signal input to EXT4/5/6 (HDMI) go out?
Does not the picture/sound of the HDMI signal input to HDMI-1/2/3 go out?

Sharp LC-40LE700E Specifications

General

Comb filter	3D
Display diagonal	40 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Power requirements	AC220V-AC240V/50Hz-60Hz
HDMI ports quantity	4
SCART ports quantity	2
Digital audio optical out	1
Cables included	AC
Product color	Black

Weight and Dimensions

Weight (with stand)	11600 g
Depth (without stand)	93.1 mm
Width (without stand)	964 mm
Height (without stand)	612 mm
