LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S

7 – 4

2.1.2 Pin Connections and short description

Pin No. Pin Name I/O Pin Function

29-44 IO0-IO7 I/O DATA INPUTS/OUTPUTS

The IO pins allow to input command, address and data and to output data during read/program opera-

tions.

The inputs are latched on the rising edge of Write Enable (WE#).

The I/O buffer float to High-Z when the device is deselected or the outputs are disabled.

16 CLE I COMMAND LATCH ENABLE

This input activates the latching of the IO inputs inside the Command Register on the Rising edge of Write

Enable (WE#).

17 ALE I ADDRESS LATCH ENABLE

This input activates the latching of the IO inputs inside the Address Register on the Rising edge of Write

Enable (WE#).

9 CE# I CHIP ENABLE

This input controls the selection of the device. When the device is busy CE# low does not deselect the

memory.

18 WE# I WRITE ENABLE

This input acts as clock to latch Command, Address and Data. The IO inputs are latched on the rise edge

of WE#.

8 RE# I READ ENABLE

The RE# input is the serial data-out control, and when active drives the data onto the I/O bus. Data is valid

REA after the falling edge of RE# which also increments the internal column address counter by one.

19 WP# I WRITE PROTECT

The WP# pin, when Low, provides an Hardware protection against undesired modify (program/erase)

operations.

7 A/B# I READY BUSY

The Ready/Busy output is an Open Drain pin that signals the state of the memory.

37 VCC — SUPPLY VOLTAGE

The VCC supplies the power for all the operations (Read, Write, Erase).

36 VSS — GROUND

1-6, 10-11, 14-15,

20-28, 33-35,

39-40, 45-48

NC — NO CONNECTION
