Sharp LC-40LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 6
62 VSS - GND
63 RS_ON O Power control for RS-232C Circuit
64 SY(N.C.)_DET O No function
65 HDMI_SCDT I No function
66 POW_SW O Power Key Detection
67 (N.C.) No function
68 (N.C.) No function
69 PL_POW O Panel Power ON
70 (N.C.)
71 CSEN2 I No function
72 AC_DET I Detection for Power moment stop
73 VSY(N.C.)/DETECT I No function
74 CBOOT O/D Main CPU boot change
75 TXD_CPU O MAIN CPU communication signal output
76 RXD_CPU I MAIN CPU communication signal input
77 PM_REQ O Communication Reset
78 SRESET O/D Main CPU Reset
79 OPC I OPC input
80 QSTEMP I Thermistor Input
81 AFT/AGC I No function
82 KEY1 I Key operation input
83 KEY2 I Key operation input
84 KEY3 I No function
85 (N.C.) I No function
86 MAIN_TEMP I No function
87 (N.C.) I No function
88 PNL_DET6 I No function
89 PNL_DET5 I No function
90 PNL_DET4 I No function
91 PNL_DET3 I No function
92 PNL_DET2 I No function
93 PNL_DET1 I No function
94 AVSS - GND
95 PNL_DET0 I No function
96 VRFF - Analogue reference voltage
97 AVCC - Analogue power supply
98 LED_R O Red LED ON/OFF
99 LED_G O LED_Green ON/OFF
100 LED_OPC O OPC_LED On/OFF
Pin No. Pin Name I/O Pin Function

Sharp LC-40LE700E Specifications

General

Comb filter	3D
Display diagonal	40 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Power requirements	AC220V-AC240V/50Hz-60Hz
HDMI ports quantity	4
SCART ports quantity	2
Digital audio optical out	1
Cables included	AC
Product color	Black

Weight and Dimensions

Weight (with stand)	11600 g
Depth (without stand)	93.1 mm
Width (without stand)	964 mm
Height (without stand)	612 mm
