LC-40/46/52/60Z5T
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] LCD PANEL MODULE Assembly (LC-40Z5T)
1 R1LK400D3GW6AA DQ J 40" LCD Panel Module Unit
2 CANGK4919TP02 AN N J Bezel Unit (Top)
3 CANGK4920TP02 AW N J Bezel Unit (Bottom)
4 CANGK4921TP02 AG N J Bezel Unit (Left/Right), x2
5 CHLDZ4763TP01 AK N J P Chassis Unit (Top)
6 CHLDZ4764TP01 AM N J P Chassis Unit (Bottom)
7 CHLDZ4765TP01 AG N J P Chassis Unit (Left)
8 CHLDZ4766TP01 AG N J P Chassis Unit (Right)
9 CANGT0321TP01 AU N J LED Angle, x2
10 CCHSM0326TP01 BE N J Back Light Chassis Unit
11 CHLDZ4767TP01 AF N J Holder Unit, x2
12 LX-BZ2568TPZZ AA N J Screw, x6 (Holder Unit)
13 LX-HZ2414TPZZ AA N J Screw, x23 (LED Angle)
14 LX-HZ2417TPZZ AA N J Screw, x40 (LED PWB)
15 PCOVP2986TPZZ AB N J LED Cable Cover (Base)
16 PCOVP2989TPZZ AB N J LED Cable Cover (Cap)
17 PSHEM0823TPZZ AQ N J Graphite Sheet, x2 (Top Left/Bottom Right)
18 PSHEM0824TPZZ AQ N J Graphite Sheet, x2 (Top Right/Bottom Left)
19 QCNWN2674TPZZ AQ N J LED Cable
20 RUNTK4833TPZZ BA N J LED-PWB, x4
21 LX-BZ2568TPZZ AA N J Screw, x12 (Bezel Lateral Side)
22 LX-BZ2574TPZZ AA N J Screw, x4
23 LX-UZ2067TPZZ AB N J Screw, x13 (Bezel)
24 PLGPA0751TPZZ BK N J Light Guide Plate
25 POFMA1275TPZZ AU N J Lens Sheet (H)
26 POFMA1276TPZZ AU N J Lens Sheet (V)
27 POFMD0620TPZZ BG N J DBEF Sheet
28 PREFL3336TPZZ AU N J Reflection Sheet
29 PSLDK3574TPZZ BF N J Micro Lens Sheet
30 PSPAK0452TPZZ AB N J Spacer, x2
