Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
107
CN603 388G359G09A0AT FIBER-OPTIC R/A 5P - BLACK 10
CN508 088G 34019K AD HDMI HEADER 19P H:2.8MM
CN507 088G 34019K AD HDMI HEADER 19P H:2.8MM
CN506 088G 34019K AD HDMI HEADER 19P H:2.8MM
CN409 311GF050A51ADJ FFC CONN 0.5MM 51P R/A 0.5S-5X-51PWB
E715 715G6840M0D000004K MAIN BOARD PCB
FCN101 388G510F501AHC RF R/A 5P 1*1 - 9.3MM
HS401 X85T804210100000LH SHIELD_MAINBOARD
HS601 X90T8009 1 HEAT SINK
SCREW3 009G6005 1 GND TERMINAL
SCREW1 009G6005 1 GND TERMINAL
SCREW2 009G6005 1 GND TERMINAL
SCREW4 009G6005 1 GND TERMINAL
Z40G0002ALL01A OTHER LABEL
709T68400XM001 COMSUMPTIVE ASSY
055G 23524 WELDING FLUX WITHOUT PB
Q49G 51100 CLEANER
Q55G 100625 TIN STICK_LOW ARGENTUM
Q02G7038 1 NUT
040G 45762420A LABEL 25X6MM
709T68400XS001 COMSUMPTIVE ASSY
055G 100610 SOLDER PASTE
Q52G170100700B00XW MESH PRINTTING_PAPER
POWER BOARD
LOCATION PART NO. DESCRIPTION
WHOLE-ASSEMBLY PLTVDQ341XXPR POWER BOARD
CAPACITOR
C9905 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M
C9906 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M
C9906 363G107K474BEC CAP X2 470NF 10% 275V 18*9*13.5 B32922L
C9905 363G107K474BEC CAP X2 470NF 10% 275V 18*9*13.5 B32922L
C9805 363G210J105GHP CAP MPP 1UF 5% 450V
C9805 363G211K105GCE CAP MPP 1UF 10% 450V 18*7*12.5MM B32672
C9815 367G215S680PNZ000A EC 68UF 20% 450V 12.5X40 2000 HR 2A ECS
C9814 367G215S680PNZ000A EC 68UF 20% 450V 12.5X40 2000 HR 2A ECS
C9814 367G215S680PRZ000A EC 68UF 20% 450V 12.5X40 2000 HR 2A 450
C9815 367G215S680PRZ000A EC 68UF 20% 450V 12.5X40 2000 HR 2A 450
C8107 367G515L560JNZ EC 56UF 20% 100V 8X20 9000 HR 1040MA EK
C8108 367G515L560JNZ EC 56UF 20% 100V 8X20 9000 HR 1040MA EK
C8108 367G515L680JRM EC 68 UF 20% 100V 8*20 9000 HR 1040 MA
C8107 367G515L680JRM EC 68 UF 20% 100V 8*20 9000 HR 1040 MA
C8123 065G080510131J F CAP CHIP 0805 100PF J 50V NPO
C8123 065G080510131J Y CAP CHIP 0805 100P 50V NP0 +/-5%
C9811 065G080510231J F CAP 0805 1NF 5% 50V NPO
C9811 065G080510231J M CAP 0805 1NF 5% 50V NP0
C8101 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9115 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9137 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9136 065G080510232K F CAP 0805 1000PF 10% 50V X7R
C9136 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C8101 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C9115 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C9137 065G080510232K Y CAP CHIP 0805 1N 50V X7R +/-10%
C9802 065G080510332K M CAP 0805 10NF 10% 50V X7R
