Sharp LC-42LB261U Service Manual

32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
115
NR9901 361G0058109MYW008A NTCR 1R 20% 3.6W SCK15018MTY503
NR9902 361G0058109MYX008A NTCR 1R 20% 3.6W 1D2-15MCSF
NR9901 361G0058109MYX008A NTCR 1R 20% 3.6W 1D2-15MCSF
IC
IC9102 056G 139 3B PC123Y82FZOF SHARP
IC9401 056G 139 3B PC123Y82FZOF SHARP
IC8102 056G 139 3B PC123Y82FZOF SHARP
IC8103 356G0700008060 LED DRIVER TPV101D DIP-8
IC8105 356G0700008060 LED DRIVER TPV101D DIP-8
IC9103 356G01585020HF SHUNT REGU TL431G-AE2-R SOT23-3
IC8104 356G01585020HF SHUNT REGU TL431G-AE2-R SOT23-3
IC8106 356G01585020HF SHUNT REGU TL431G-AE2-R SOT23-3
IC8100 356G0379008228 AC/DC PF6002AS SOP-8
IC9801 356G0379008232 PFC SSC-2005S SOP-8
IC9100 356G0379213 AC/DC SSC2S110 SOP-8
OTHERS
CN8101 033G380212B YH WAFER 12P 2.0 DIP
CN8101 033G380212B YH L WAFER 12.0MM 12P
CN9100 311GW200C16BBL CONN 2.0MM 16P R/A B2000W16HTKE
CN9100 311GW200C16BBX ONN 2.0MM 16P R/A W2010-16RVA-S04,B200
CN9902 387G050147F0ST AC R/A 2P 12.81MM
CN9902 006G 31500 EYELET
E715 715G6335P01003003H POWER BOARD PCB
E715 715G6335P01003003M POWER BOARD PCB
GND2 009G6005 1 GND TERMINAL
GND3 009G6005 1 GND TERMINAL
GND1 009G6005 1 GND TERMINAL
HD8106 X90G070810100000BF HEAT SINK
HD9105 Q90T0236007A0000SY HEAT SINK
HD9901 Q90T022300200000SY HEAT SINK
HQ9100 Q90G0219 4 HEAT SINK ÐͲÄ/PROFILE
HQ8100 Q90T0236 7 HEAT SINK
HS9801 Q90G0219 3 HEAT SINK
HS8105 X90G070710100000BF HEAT SINK
HS8103 X90G070710100000BF HEAT SINK
SG9901 362G0010501MIT SPARK GAP 500V -20/+30%
SG9904 362G0010501MIT SPARK GAP 500V -20/+30%
SG9903 362G0010501MIT SPARK GAP 500V -20/+30%
SG9902 362G0010501MIT SPARK GAP 500V -20/+30%
T9101 380GL32P170L00 X'FMR 360UH 10% 5UH ER31 PT-018859
T9101 380GL32P170N00 X'FMR 360UH 10% 5UH ER31 YUVA-2133-31
T8101 380GL52P161L00 X'FMR 190 UH 10% 5UH MAX PQ38 00036100
T9101 006G 31 4 1.7MM RIVET
T8101 006G 31500 EYELET
Z40G0002ALL01A OTHER LABEL
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
705TAD57069 TRANSISTOR ASSY (Q8100 ASSY)
0M1G1730 8120 SCREW
705TAD93999 NA
0M1G1730 8120 SCREW
705TXD57085 Q9801 ASSY
0M1G1730 8120 SCREW
705TXD57900 Q9100 ASSY
0M1G1730 8120 SCREW
