32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
38
U401 MSD8220LB
U601 TAS5729
+3V3TUNER
U401 MSD8220LB
PANEL LVDS Pow er
Q702 AO4449-7A
For Audio Amplifier
U403 W25Q32FVSSIG
5V_SW
U705 AT1529 Fo r M SD8220LB-S9
Fo r M SD8220LB-S9
U707
TPS54339DDAR
P12V
3V3_STB
VCCK
P12V_AUD
U701 AP1117E33L-13-77
For Re s e t IC
For SPI Flas h
TU101 TUNER
DDRV
Fo r M SD8220LB-S9
+12V_AUD
U401 MSD8220LB
Q104 AO4449-7A
+5VSB
U102 AP1117E33L-13-77
U405 G690H293T73
U706 AP1117DG-13 1A ADJ
Fo r TUNER 3.3V
